Запчасти Komatsu WA450-3L FIG. M-A ЗАДН. КРЫЛОS ЧАСТИ КОРПУСА

1

421-54-24150

FENDER, REAR - L.H.

SN: A30001-UP-UP

1шт.

2

421-54-24160

FENDER, REAR - R.H.

SN: A30001-UP-UP

1шт.

3

01435-01225

BOLT

SN: A30001-UP-UP

12шт.

4

01435-01220

BOLT

SN: A30001-UP-UP

4шт.

5

01643-31232

WASHER

SN: A30001-UP-UP

16шт.

6

421-54-24380

FLAP, MUD - L.H. REAR FENDER

SN: A30001-UP-UP

2шт.

7

421-54-24390

BRACKET, MUD FLAP

SN: A30001-UP-UP

2шт.

8

01435-01020

BOLT

SN: A30001-UP-UP

8шт.

9

421-54-24510

BRACKET - FENDER TO FLOOR

SN: A30001-UP-UP

2шт.

10

01435-01220

BOLT

SN: A30001-UP-UP

6шт.

11

566-54-23460

DOVETAIL, LOWER

SN: A30001-UP-UP

4шт.

12

566-54-23470

DOVETAIL, UPPER

SN: A30001-UP-UP

4шт.

13

01435-00616

BOLT

SN: A30001-UP-UP

16шт.

14

423-54-11962

HOOK

SN: A30001-UP-UP

2шт.

15

01435-00820

BOLT

SN: A30001-UP-UP

4шт.

16

421-54-24580

BRACKET, L.H.

SN: A30001-UP-UP

1шт.

17

421-54-24590

BRACKET, R.H.

SN: A30001-UP-UP

1шт.

18

01435-01220

BOLT

SN: A30001-UP-UP

4шт.

19

423-54-11951

CATCH ASSEMBLY

SN: A30001-UP-UP

2шт.

20

01435-00820

BOLT

SN: A30001-UP-UP

4шт.

21

01584-00806

NUT

SN: A30001-UP-UP

4шт.

22

421-54-22990

PLUG

SN: A30001-UP-UP

4шт.

23

09805-03000

DECAL, SAFETY - REAR FENDER, ENGLISH

SN: A30001-UP-UP

2шт.

|$24

OR

-1шт.

23

09805-05000

DECAL, SAFETY - REAR FENDER, FRENCH

SN: A30001-UP-UP

2шт.

|$28

OR

-1шт.

23

09805-01000

DECAL, SAFETY - REAR FENDER, SPANISH

SN: A30001-UP-UP

2шт.

|$31

-1шт.

|$32

F1 - THIS PART IS REPLACED BY P/N 421-54-24151 REAR FENDER - L.H. ANDP/N 421-54-24511 BRACKET.

-1шт.

|$33

-1шт.

|$34

-1шт.

|$35

F2 - THIS PART IS REPLACED BY P/N 421-54-24161 REAR FENDER - R.H. ANDP/N 421-54-24511 BRACKET.

-1шт.

|$36

-1шт.
