Запчасти Komatsu WA450-3L FIG. A-A КОЛЕНВАЛ ДВИГАТЕЛЬ

1

1304 956 H1

CRANKSHAFT, ENGINE

1шт.

2

1246 143 H1

KEY, PLAIN WOODRUFF

1шт.

3

1304 957 H1

GEAR, CRANKSHAFT

1шт.

|$3

1317 089 H91

KIT, REAR SEAL

1шт.

4

1240 556 H1

SEAL, OIL

1шт.

|$5

1246 216 H1

BOLT - M8-1.25 X 20

12шт.

|$6

1241 690 H2

GASKET, CARRIER

1шт.

5

1296 127 H1

SLEEVE, WEAR - FRONT

1шт.

|$8

1246 138 H92

SET, MAIN BEARING - STANDARD

1шт.

6

1246 139 H1

BEARING, MAIN - UPPER

7шт.

7

1246 140 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

4шт.

|$13

OR

-1шт.

|$15

1240 512 H92

SET, MAIN BEARING - 0.25 MM OVERSIZE

1шт.

6

1240 434 H1

BEARING, MAIN - UPPER

7шт.

7

1240 438 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

4шт.

|$20

OR

-1шт.

|$22

1240 513 H92

SET, MAIN BEARING - 0.50 MM OVERSIZE

1шт.

6

1240 435 H1

BEARING, MAIN - UPPER

7шт.

7

1240 439 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

4шт.

|$27

OR

-1шт.

|$29

1240 514 H92

SET, MAIN BEARING - 0.75 MM OVERSIZE

1шт.

6

1240 436 H1

BEARING, MAIN - UPPER

7шт.

7

1240 440 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

4шт.

|$34

OR

-1шт.

|$36

1240 515 H92

SET, MAIN BEARING - 1.00 MM OVERSIZE

1шт.

6

1240 437 H1

BEARING, MAIN - UPPER

7шт.

7

1240 441 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

4шт.

|$41

OR

-1шт.

|$43

1310 912 H92

SET, MAIN BEARING - STANDARD

1шт.

6

1246 139 H1

BEARING, MAIN - UPPER

7шт.

7

1246 140 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

2шт.

9

1316 118 H1

BEARING, THRUST - NO. 4 MAIN

2шт.

|$48

1310 915 H92

SET, MAIN BEARING - 0.25 MM OVERSIZE

1шт.

6

1240 434 H1

BEARING, MAIN - UPPER

7шт.

7

1240 438 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

2шт.

9

1316 118 H1

BEARING, THRUST - NO. 4 MAIN

2шт.

|$54

OR

-1шт.

|$56

1310 916 H92

SET, MAIN BEARING - 0.50 MM OVERSIZE

1шт.

6

1240 435 H1

BEARING, MAIN - UPPER

7шт.

7

1240 439 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

2шт.

9

1316 118 H1

BEARING, THRUST - NO. 4 MAIN

2шт.

|$62

OR

-1шт.

|$64

1310 917 H92

SET, MAIN BEARING - 0.75 MM OVERSIZE

1шт.

6

1240 436 H1

BEARING, MAIN - UPPER

7шт.

7

1240 440 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

2шт.

9

1316 118 H1

BEARING, THRUST - NO. 4 MAIN

2шт.

|$70

OR

-1шт.

|$72

1310 918 H92

SET, MAIN BEARING - 1.00 MM OVERSIZE

1шт.

6

1240 437 H1

BEARING, MAIN - UPPER

7шт.

7

1240 441 H1

BEARING, MAIN - LOWER

7шт.

8

1316 117 H1

BEARING, THRUST - NO. 4 MAIN

2шт.

9

1316 118 H1

BEARING, THRUST - NO. 4 MAIN

2шт.
