Запчасти Komatsu WA450-3L FIG. K-A СИДЕНЬЕ ОПЕРАТОРА - С ВОЗД. ПОДВЕСКОЙ - KAB КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

421-57-21510

SEAT, SUSPENSION TYPE

SN: A30001-UP-UP

1шт.

|$1

BS162663

UPPER ASSEMBLY, FABRIC

SN: A30001-UP-UP

1шт.

1

NSS

FRAME KIT, SEAT

SN: A30001-UP-UP

1шт.

2

BS162664

COVER, BACK

SN: A30001-UP-UP

1шт.

3

206-57-A1430

FOAM, BACK

SN: A30001-UP-UP

1шт.

4

BS157146

COVER, SEAT

SN: A30001-UP-UP

1шт.

5

206-57-A1450

FOAM, SEAT

SN: A30001-UP-UP

1шт.

6

BS163369

HEIGHT RISER ASSEMBLY KIT

SN: A30001-UP-UP

1шт.

7

BS163368

LATCH KIT, HEIGHT RISER

SN: A30001-UP-UP

1шт.

8

BS162056

SPRING KIT, HEIGHT RISER

SN: A30001-UP-UP

1шт.

9

BS164188

HANDLE KIT

SN: A30001-UP-UP

1шт.

10

BS162032

ADJUSTMENT KIT, CABLE

SN: A30001-UP-UP

1шт.

11

BS157230

SUSPENSION ASSEMBLY

SN: A30001-UP-UP

1шт.

12

BS156717

STOP KIT, BUMP/UP

SN: A30001-UP-UP

1шт.

13

BS156737

ADJUSTMENT KIT, WEIGHT

SN: A30001-UP-UP

1шт.

14

BS156738

BEARING KIT, SUSPENSION

SN: A30001-UP-UP

1шт.

15

BS157228

DAMPER KIT

SN: A30001-UP-UP

1шт.

16

BS162035

ADJUSTMENT KIT, SLIDERAIL - FORWARD/BACKWARD)

SN: A30001-UP-UP

1шт.

17

BS152879

HANDLE, SLIDERAIL

SN: A30001-UP-UP

1шт.

18

BS151185

HEADREST KIT

SN: A30001-UP-UP

1шт.

19

BS165216

ARMREST KIT, L.H.

SN: A30001-UP-UP

1шт.

|$21

BS166386

ARMREST KIT, R.H.

SN: A30001-UP-UP

1шт.

|$22

-1шт.

|$23

F1 - ALL KITS HAVE REQUIRED MOUNTING HARDWARE.

-1шт.

|$24

-1шт.
