Запчасти Komatsu WA450-3L FIG. H-A ЦИЛИНДР ASSEMBLY - РАЗГРУЗКА - HI-LIFT ГИДРАВЛИКА

|$0

707-01-02131

CYLINDER ASSEMBLY, DUMP

SN: A30001-UP-UP

1шт.

1

NSS

CYLINDER

SN: A30001-UP-UP

1шт.

2

707-76-12130

BUSHING

SN: A30001-UP-UP

1шт.

3

NSS

HEAD, CYLINDER

SN: A30001-UP-UP

1шт.

4

707-52-11010

BUSHING

SN: A30001-UP-UP

1шт.

5

NSS

PACKING, ROD

SN: A30001-UP-UP

1шт.

6

NSS

SEAL, DUST

SN: A30001-UP-UP

1шт.

7

07179-13114

RING, SNAP

SN: A30001-UP-UP

1шт.

8

NSS

O-RING

SN: A30001-UP-UP

1шт.

9

NSS

RING, BACK-UP

SN: A30001-UP-UP

1шт.

10

01010-82075

BOLT

SN: A30001-UP-UP

12шт.

11

01643-32060

WASHER

SN: A30001-UP-UP

12шт.

12

707-58-10290

ROD, PISTON

SN: A30001-UP-UP

1шт.

13

707-76-12030

BUSHING

SN: A30001-UP-UP

1шт.

14

NSS

O-RING

SN: A30001-UP-UP

1шт.

15

NSS

RING, BACK-UP

SN: A30001-UP-UP

2шт.

16

707-36-20400

PISTON

SN: A30001-UP-UP

1шт.

17

NSS

RING, PISTON

SN: A30001-UP-UP

1шт.

18

NSS

RING, WEAR

SN: A30001-UP-UP

1шт.

19

707-40-20030

SPACER

SN: A30001-UP-UP

2шт.

20

01010-E1245

BOLT

SN: A30001-UP-UP

6шт.

N/I

707-52-90780

BUSHING

SN: A30001-UP-UP

1шт.

|$22

707-99-73020

SERVICE KIT, DUMP CYLINDER

SN: A30001-UP-UP

1шт.

|$23

-1шт.

|$24

F1 - INCLUDED IN SERVICE KIT.

-1шт.

|$26

-1шт.

|$27

F2 - REPLACED BY P/N 707-01-02133 WITH A BUFFER RING ADDED. FOR ALLCOMPONENTS OF P/N 707-01-02131, SEE PARTS AND SERVICE NEWSAA97171, PAGE 33 OF 33.

-1шт.

|$29

-1шт.

|$30

F3 - IN BREAKDOWN OF P/N 707-01-2133, ITEM 3 IS HEAD P/N 707-27-20810AND ITEM 4 IS BUSHING P/N 707-51-10640. N/I BUSHING P/N 707-52-90780IS IN BREAKDOWN OF P/N 707-01-02133 ONLY.

-1шт.

|$31

-1шт.
