Запчасти Komatsu WA450-3L FIG. H-A ЦИЛИНДР ASSEMBLY - РАЗГРУЗКА - СТАНДАРТН. LIFT ГИДРАВЛИКА

|$0

707-01-03251

CYLINDER ASSEMBLY, DUMP

SN: A30001-UP-UP

1шт.

1

NSS

CYLINDER

SN: A30001-UP-UP

1шт.

2

707-76-12130

BUSHING

SN: A30001-UP-UP

1шт.

3

NSS

HEAD, CYLINDER

SN: A30001-UP-UP

1шт.

4

707-52-11010

BUSHING

SN: A30001-UP-UP

1шт.

5

NSS

PACKING, ROD

SN: A30001-UP-UP

1шт.

6

NSS

SEAL, DUST

SN: A30001-UP-UP

1шт.

7

07179-13114

RING, SNAP

SN: A30001-UP-UP

1шт.

8

NSS

O-RING

SN: A30001-UP-UP

1шт.

9

NSS

RING, BACK-UP

SN: A30001-UP-UP

1шт.

10

01010-82075

BOLT

SN: A30001-UP-UP

12шт.

11

01643-32060

WASHER

SN: A30001-UP-UP

12шт.

12

707-58-10090

ROD, PISTON

SN: A30001-UP-UP

1шт.

13

707-76-12030

BUSHING

SN: A30001-UP-UP

1шт.

14

NSS

O-RING

SN: A30001-UP-UP

1шт.

15

NSS

RING, BACK-UP

SN: A30001-UP-UP

2шт.

16

707-36-20400

PISTON

SN: A30001-UP-UP

1шт.

17

NSS

RING, PISTON

SN: A30001-UP-UP

1шт.

18

NSS

RING, WEAR

SN: A30001-UP-UP

1шт.

19

707-40-20030

SPACER

SN: A30001-UP-UP

2шт.

20

01010-E1245

BOLT

SN: A30001-UP-UP

6шт.

|$21

707-99-73020

SERVICE KIT, DUMP CYLINDER

SN: A30001-UP-UP

1шт.

|$22

-1шт.

|$23

F1 - INCLUDED IN SERVICE KIT.

-1шт.

|$25

-1шт.

|$26

F2 - REPLACED BY P/N 707-01-03253 WITH A BUFFER RING ADDED.NO BREAKDOWN AVAILABLE. FOR ALL COMPONENTS OF P/N 707-01-03251,SEE PARTS AND SERVICE NEWS AA97171, PAGE 31 OF 33.

-1шт.

|$27

-1шт.
