1
07000-13048
O-RING
SN: A30001-UP-UP
1шт.
2
421-875-3121
TUBE - HYDRAULIC TANK TO DIVIDER VALVE
SN: A30001-UP-UP
1шт.
3
07260-04120
HOSE - HYDRAULIC TANK TO DIVIDER VALVE
SN: A30001-UP-UP
1шт.
4
07281-00609
CLAMP, HOSE
SN: A30001-UP-UP
4шт.
5
421-875-3143
TUBE - AT DIVIDER VALVE
SN: A30001-UP-UP
1шт.
6
01435-01230
BOLT
SN: A30001-UP-UP
4шт.
7
07000-13042
O-RING - BETWEEN TUBE AND DIVIDERVALVE
SN: A30001-UP-UP
1шт.
8
01435-01065
BOLT - MOUNT TUBE TO DIVIDER VALVE
SN: A30001-UP-UP
2шт.
9
04065-01910
RING, SNAP
SN: A30001-UP-UP
1шт.
10
VALVE, DIVIDER (SEE FIG. H4411-01A0)
SN: A30001-UP-UP
-1шт.
11
07000-13040
O-RING - BETWEEN VALVE AND PUMP
SN: A30001-UP-UP
2шт.
12
07000-12012
O-RING - BETWEEN VALVE AND PUMP
SN: A30001-UP-UP
2шт.
13
01011-81045
BOLT, MOUNT DIVIDER VALVE
SN: A30001-UP-UP
2шт.
14
01011-81085
BOLT, MOUNT DIVIDER VALVE
SN: A30001-UP-UP
2шт.
15
01643-31032
WASHER
SN: A30001-UP-UP
4шт.
16
PUMP ASSEMBLY, GROUND DRIVENSTEERING - SAM2-50 (SEE FIG. H0210-01A0)
SN: A30001-UP-UP
-1шт.
17
07040-12012
PLUG
SN: A30001-UP-UP
1шт.
18
07002-12034
O-RING
SN: A30001-UP-UP
1шт.
19
07000-12105
O-RING
SN: A30001-UP-UP
1шт.
20
01010-81235
BOLT, MOUNT GROUND DRIVEN STEERINGPUMP
SN: A30001-UP-UP
2шт.
21
01643-31232
WASHER
SN: A30001-UP-UP
2шт.
22
424-875-1680
PLUG
SN: A30001-UP-UP
1шт.
23
20D-62-17150
O-RING
SN: A30001-UP-UP
1шт.
24
04064-04018
RING, SNAP
SN: A30001-UP-UP
1шт.
25
07000-02085
O-RING
SN: A30001-UP-UP
1шт.
26
06040-06208
BEARING, BALL
SN: A30001-UP-UP
1шт.
27
714-11-11350
RETAINER
SN: A30001-UP-UP
1шт.
28
01010-31230
BOLT, MOUNT COVER
SN: A30001-UP-UP
3шт.
29
714-07-18450
JOINT
SN: A30001-UP-UP
1шт.
30
SHAFT, OUTPUT (SEE FIG. F4350-55A0)
SN: A30001-UP-UP
-1шт.
31
01252-30816
BOLT
SN: A30001-UP-UP
1шт.
32
01643-30823
WASHER
SN: A30001-UP-UP
1шт.
33
07042-20108
PLUG
SN: A30001-UP-UP
1шт.
34
01435-01040
BOLT
SN: A30001-UP-UP
2шт.
35
08053-01512
CLIP
SN: A30001-UP-UP
2шт.
36
01435-01016
BOLT
SN: A30001-UP-UP
1шт.
37
TRANSMISSION ASSEMBLY(SEE FIG. F4350-51A0)
SN: A30001-UP-UP
-1шт.
38
TANK, HYDRAULIC (SEE FIG. H0110-01A0)
SN: A30001-UP-UP
-1шт.
