Запчасти Komatsu WA450-3L FIG. H-A ГИДР. НАСОС. - GROUND ПРИВОДN РУЛЕВ. УПРАВЛЕНИЕ ГИДРАВЛИКА

|$0

704-30-34110

PUMP ASSEMBLY, GROUND DRIVENSTEERING - SAM2-50

SN: A30001-UP-UP

1шт.

1

704-37-02030

BRACKET

SN: A30001-UP-UP

1шт.

2

704-37-34010

CASE, GEAR

SN: A30001-UP-UP

1шт.

3

704-37-02180

COVER

SN: A30001-UP-UP

1шт.

4

705-17-34410

GEAR, DRIVE

SN: A30001-UP-UP

1шт.

5

705-17-34511

GEAR, DRIVEN

SN: A30001-UP-UP

1шт.

6

704-37-02350

BEARING, NEEDLE

SN: A30001-UP-UP

4шт.

7

704-37-02610

PLATE, SIDE

SN: A30001-UP-UP

2шт.

8

704-37-02440

RING, BACK-UP

SN: A30001-UP-UP

4шт.

9

704-37-02470

RING, SEAL

SN: A30001-UP-UP

4шт.

10

704-37-02450

RING, BACK-UP

SN: A30001-UP-UP

4шт.

11

07000-12100

O-RING

SN: A30001-UP-UP

2шт.

12

04020-01024

PIN, DOWEL

SN: A30001-UP-UP

4шт.

13

705-17-04630

BOLT

SN: A30001-UP-UP

1шт.

14

705-17-04980

WASHER, SPRING

SN: A30001-UP-UP

4шт.

15

705-17-02810

SEAL, OIL

SN: A30001-UP-UP

1шт.

16

04065-04018

RING, SNAP

SN: A30001-UP-UP

1шт.

|$17

-1шт.

|$18

F1 - PARTS SUPPLIED ONLY TO DESIGNATED DEALERS WHICH ARE EQUIPPEDWITH A HYDRAULIC PUMP TESTER.

-1шт.

|$19

-1шт.
