Запчасти Komatsu WA450-3L FIG. F-A ПЕРЕДНИЙ МОСТ - ASSEMBLY СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

421-22-20001

AXLE ASSEMBLY, FRONT - STANDARD

SN: A30001-UP-UP

1шт.

|$2

OR

-1шт.

|$4

421-22-20051

AXLE ASSEMBLY, FRONT -WITH LIMITED SLIP DIFFERENTIAL

SN: A30001-UP-UP

1шт.

1

421-22-23110

HOUSING

SN: A30001-UP-UP

1шт.

2

07044-13620

PLUG, DRAIN

SN: A30001-UP-UP

1шт.

3

07041-13618

PLUG

SN: A30001-UP-UP

2шт.

4

07002-13634

ORING

SN: A30001-UP-UP

3шт.

5

07030-01030

BREATHER

SN: A30001-UP-UP

1шт.

6

421-22-13230

SHAFT, TUBE

SN: A30001-UP-UP

2шт.

7

07040-11007

PLUG

SN: A30001-UP-UP

4шт.

8

07002-11023

ORING

SN: A30001-UP-UP

4шт.

9

07000-15220

ORING

SN: A30001-UP-UP

2шт.

10

01252-71040

BOLT

SN: A30001-UP-UP

6шт.

11

01010-62495

BOLT

SN: A30001-UP-UP

32шт.

12

01643-32460

WASHER

SN: A30001-UP-UP

32шт.

13

DIFFERENTIAL ASSEMBLY, FRONT (SEE FIG. F4400-03A0)

SN: A30001-UP-UP

-1шт.

|$19

OR

-1шт.

13

DIFFERENTIAL, FRONT - LIMITED SLIP (SEE FIG. F4400-04A0)

SN: A30001-UP-UP

-1шт.

14

04020-01638

PIN, DOWEL

SN: A30001-UP-UP

1шт.

15

07000-15485

ORING

SN: A30001-UP-UP

1шт.

16

01010-61450

BOLT

SN: A30001-UP-UP

17шт.

17

01010-61455

BOLT

SN: A30001-UP-UP

3шт.

18

01643-31445

WASHER

SN: A30001-UP-UP

20шт.

19

421-22-13290

BRACKET

SN: A30001-UP-UP

1шт.

20

01010-E1045

BOLT

SN: A30001-UP-UP

1шт.

21

01643-31032

WASHER

SN: A30001-UP-UP

1шт.

22

NSS

PLATE, NAME

SN: A30001-UP-UP

1шт.

23

04418-03060

SCREW

SN: A30001-UP-UP

4шт.

24

421-22-23310

ADAPTER

SN: A30001-UP-UP

1шт.

N/I

DRIVE, FINAL - FRONT AXLE (SEE FIG. F4400-05A0)

SN: A30001-UP-UP

-1шт.

N/I

BRAKE, WHEEL - FRONT AXLE (SEE FIG. F4400-01A0)

SN: A30001-UP-UP

-1шт.

|$35

-1шт.

|$36

F1 - FRONT AXLE ASSEMBLY - STANDARD DIFFERENTIAL P/N 421-22-20001 AND FRONT AXLE ASSEMBLY - LIMITED SLIP DIFFERENTIAL P/N 421-22-20051 AXLES ARE THE SAME EXCEPT FOR THE DIFFERENTIAL.

-1шт.

|$38

-1шт.

|$39

F2 - USED ONLY FOR 421-22-20001 AXLE APPLICATION.

-1шт.

|$41

-1шт.

|$42

F3 - USED ONLY FOR 421-22-20051 AXLE APPLICATION.

-1шт.

|$43

-1шт.
