Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|1
714-07-10041
TRANSMISSION ASS'Y,E
SN: 54001-UP
1шт.
|$$3
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.
-1шт.
1
714-07-15400
VALVE ASS'Y,FLOW CONTROL
SN: 53001-UP
1шт.
4
01252-31065
BOLT
SN: 53001-UP
1шт.
5
01252-31055
BOLT
SN: 53001-UP
3шт.
7
714-07-15600
VALVE ASS'Y,ACCUMULATOR
SN: 54001-UP
1шт.
11
714-07-15012
VALVE ASS'Y,TRANSMISSION
SN: 55001-UP
1шт.
|11
714-07-15011
VALVE ASS'Y,TRANSMISSION
SN: 54001-55000
1шт.
12
714-07-16670
BOLT
SN: 54001-UP
2шт.
|20
714-07-16500
VALVE ASS'Y,CHECK
SN: 54001-UP
1шт.
20
714-07-16580
SLEEVE
SN: 54001-UP
1шт.
21
714-07-16570
PLUG
SN: 54001-UP
1шт.
Выбрано товаров: 28
