Запчасти Komatsu WA450-3-X ТРАНСМИССИЯ (4 МУФТА)(№-) ТРАНСМИССИЯ

|1

714-07-10000

TRANSMISSION ASS'Y

SN: 60001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2201 TO 2271.

-1шт.

|1

714-07-13500

CLUTCH ASS'Y,3RD AND 4TH

SN: 60001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2225 AND 2226.

-1шт.

1

714-07-13511

SHAFT ASS'Y

SN: 60001-UP

1шт.

2

714-07-12661

PISTON,4TH

SN: 60001-UP

1шт.

3

714-07-12740

RING,SEAL

SN: 60001-UP

1шт.

4

714-07-19320

RING,SEAL

SN: 60001-UP

1шт.

5

714-07-12670

DISC

SN: 60001-UP

6шт.

6

714-07-12680

PLATE,SEPARATE

SN: 60001-UP

7шт.

7

714-07-12780

SPRING,WAVE

SN: 60001-UP

6шт.

8

714-07-12711

PLATE,END

SN: 60001-UP

1шт.

9

714-07-12720

RING,SNAP

SN: 60001-UP

1шт.

10

714-07-13620

GEAR¤ 53 TEETH,4TH

SN: 60001-UP

1шт.

11

714-07-12280

BEARING,NEEDLE

SN: 60001-UP

2шт.

12

714-07-12220

WASHER,THRUST

SN: 60001-UP

2шт.

13

714-07-12250

SPACER

SN: 60001-UP

1шт.

14

06040-06215

BEARING

SN: 60001-UP

1шт.

15

714-07-12290

RING,SEAL

SN: 60001-UP

3шт.
