Запчасти Komatsu WA450-3-H КЛАПАН АККУМУЛЯТОРА ТРАНСМИССИИ ТРАНСМИССИЯ

|1

714-07-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 64001-UP

1шт.

|1

714-07-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-64000

1шт.

|$$3

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.

-1шт.

|1

714-07-15600

VALVE ASS'Y,ACCUMULATOR

SN: 63001-UP

1шт.

|1

714-07-15660

BODY ASS'Y

SN: 63001-UP

1шт.

1

0

BODY

SN: 63001-UP

1шт.

2

07043-70211

PLUG

SN: 63001-UP

5шт.

3

07042-70211

PLUG

SN: 63001-UP

6шт.

4

714-07-15850

COVER

SN: 63001-UP

2шт.

5

714-07-15610

VALVE

SN: 63001-UP

3шт.

6

07000-03035

O-RING (K2)

SN: 63001-UP

6шт.

7

01010-81025

BOLT

SN: 63001-UP

8шт.

8

01643-31032

WASHER

SN: 63001-UP

8шт.

9

714-07-16470

SPRING

SN: 63001-UP

3шт.

10

714-11-15370

STOPPER

SN: 63001-UP

3шт.
