Запчасти Komatsu WA450-3-H ТРАНСМИССИЯ (РЕВЕРС, 2-Я МУФТА) ТРАНСМИССИЯ

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|1

714-07-10041

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 64001-UP

1шт.

|1

714-07-10040

TRANSMISSION ASS'Y,(FOR EMERGENCY STEERING)

SN: 63001-64000

1шт.

|$$4

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-69A0.

-1шт.

|1

714-07-13000

CLUTCH ASS'Y,REVERSE AND 2ND

SN: 63001-UP

1шт.

1

714-07-13010

SHAFT ASS'Y

SN: 63001-UP

1шт.

2

714-07-12911

PISTON,REVERSE

SN: 63001-UP

1шт.

3

714-07-12661

PISTON,2ND

SN: 63001-UP

1шт.

4

714-07-12670

DISC,2ND

SN: 63001-UP

6шт.

5

714-07-19720

DISC,REVERSE

SN: 63001-UP

11шт.

6

714-07-12680

PLATE,SEPARATE

SN: 63001-UP

19шт.

7

714-07-12691

SPRING,WAVE

SN: .-UP

11шт.

|7

0

SPRING,WAVE

SN: 63001-.

11шт.

8

714-07-12780

SPRING,WAVE

SN: 63001-UP

6шт.

9

714-07-12711

PLATE,END

SN: 63001-UP

2шт.

10

714-07-12720

RING,SEAL

SN: 63001-UP

2шт.

11

714-07-19320

RING,SEAL

SN: 63001-UP

2шт.

12

714-08-19220

RING,SEAL

SN: 63001-UP

1шт.

13

714-07-12740

RING,SEAL

SN: 63001-UP

1шт.

14

714-07-12220

WASHER,THRUST

SN: 63001-UP

4шт.

15

714-07-12920

WASHER,THRUST

SN: 63001-UP

1шт.

16

714-07-12250

SPACER

SN: 63001-UP

2шт.

17

56B-15-19420

BEARING,NEEDLE

SN: 65013-UP

4шт.

|17

714-07-12281

BEARING,NEEDLE

SN: (106967)-(107853)

4шт.

|17

0

BEARING,NEEDLE

SN: 63001-(106966)

4шт.

18

714-07-12430

GEAR¤ 46 TEETH,REVERSE

SN: 63001-UP

1шт.

19

714-07-13151

GEAR¤ 26-50 TEETH,2ND

SN: 63001-UP

1шт.

20

06040-06315

BEARING

SN: 63001-UP

1шт.

21

714-07-19340

BEARING

SN: 63001-UP

1шт.

22

714-07-12290

RING,SEAL

SN: 63001-UP

3шт.
