Запчасти Komatsu WA450-2 FIG NO. E CRANKING МОТОР КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

|$0

1251 635 H92

MOTOR ASSEMBLY, CRANKING

1шт.

1

1223 255 H1

HOUSING ASSEMBLY, DRIVE END

1шт.

2

NSS

BUSHING, DRIVE END

1шт.

3

NSS

O-RING, BETWEEN HOUSINGS

1шт.

4

NSS

PLUG, WICK

1шт.

5

NSS

WICK, OIL RESERVOIR

1шт.

6

NSS

HOUSING, DRIVE END

1шт.

N/I

NSS

BOLT, MOUNTING

6шт.

7

1223 260 H91

HOUSING

1шт.

8

1223 259 H1

DRIVE, MOTOR

1шт.

9

NSS

HOUSING ASSEMBLY, LEVER

1шт.

10

NSS

RING, RETAINING - SHIFT LEVER SHAFT

1шт.

11

1223 258 H91

HOUSING, LEVER

1шт.

12

NSS

SEAL, OIL - LEVER HOUSING

1шт.

13

NSS

WASHER, BRAKE

1шт.

14

NSS

O-RING, LEVER SHAFT (1/2 OD)

1шт.

15

NSS

O-RING, LEVER SHAFT (3/8 OD)

1шт.

16

NSS

SHAFT, SHIFT LEVER

1шт.

17

NSS

LEVER, SHIFT

1шт.

18

NSS

WICK, LEVER HOUSING

1шт.

19

NSS

PLUG, WICK

1шт.

20

NSS

BUSHING, LEVER HOUSING

1шт.

21

NSS

O-RING, BETWEEN HOUSINGS

1шт.

22

NSS

O-RING, BETWEEN SWITCH AND LEVER HOUSING

1шт.

N/I

1245 107 H1

SCREW, LEVER HOUSING

1шт.

23

NSS

SPACER, DRIVE END

1шт.

24

1277 066 H1

CABLE, SOLENOID SWITCH TO C.E. TERMINAL

1шт.

N/I

120 239

WASHER, LOCK - AT SOLENOID SWITCH

1шт.

N/I

1211 267 H1

NUT, AT SOLENOID SWITCH

1шт.

N/I

NSS

WASHER, FLAT - AT FRAME END

1шт.

N/I

NSS

WASHER, LOCK - AT FRAME END

1шт.

N/I

NSS

NUT, AT END FRAME

1шт.

N/I

NSS

NUT AND WASHER, AT END FRAME

1шт.

25

1228 450 H1

PLUNGER, SHIFT LEVER

1шт.

26

1210 070 H1

WASHER, PLUNGER

1шт.

27

1210 071 H1

BOOT, PLUNGER

1шт.

28

1210 072 H1

RETAINER, SPRING

1шт.

29

1210 073 H1

SPRING, PLUNGER

1шт.

30

1210 074 H1

RETAINER, SPRING

1шт.

31

213 262 R1

RING, RETAINING

1шт.

32

NSS

NUT, LOCK - PLUNGER ROD GUIDE ADJUST

1шт.

33

1284 359 H1

SWITCH, SOLENOID

1шт.

N/I

NSS

SCREW AND WASHER, SWITCH MOUNTING

3шт.

34

1211 271 H1

INSULATOR, FIELD COIL - DRIVE END

1шт.

35

1211 263 H1

SHOE, POLE

4шт.

36

1245 108 H1

SCREW, POLE SHOE

8шт.

37

1228 453 H1

INSULATOR, FIELD COIL

1шт.

38

NSS

INSULATOR, INSIDE FRAME

1шт.

39

NSS

INSULATOR, OUTSIDE FRAME

1шт.

40

1228 452 H1

CONNECTOR, FIELD COIL TO SOLENOID

1шт.

N/I

NSS

NUT AND WASHER - AT SOLENOID

1шт.

N/I

NSS

BOLT, MOUNTING - AT FIELD COIL

1шт.

N/I

NSS

WASHER, FLAT - AT FIELD COIL

1шт.

41

1228 454 H1

PIN, SPRING

2шт.

42

1223 256 H1

ARMATURE

1шт.

43

NSS

WASHER, THRUST

1шт.

44

1228 605 H1

COIL ASSEMBLY, FIELD

1шт.

45

1284 360 H91

PLATE, BRUSH

1шт.

N/I

NSS

SCREW AND WASHER, THRU END FRAME TO PLATE

6шт.

N/I

NSS

SCREW, FIELD COIL TO PLATE

4шт.

46

NSS

BRUSH

4шт.

47

NSS

SPRING, BRUSH

4шт.

48

1223 265 H1

LEAD, TERMINAL

1шт.

49

NSS

O-RING, BETWEEN HOUSINGS

1шт.

50

NSS

PACKAGE, TERMINAL INSULATOR

1шт.

51

NSS

HOUSING ASSEMBLY, COMMUTATOR END

1шт.

52

NSS

HOUSING, END FRAME

1шт.

53

NSS

WICK, OIL RESERVOIR

1шт.

54

NSS

PLUG, WICK

1шт.

55

NSS

BUSHING, END FRAME

1шт.

56

1210 066 H1

PLUG, INSPECTION - LEVER HOUSING

1шт.

57

NSS

GASKET, INSPECTION PLUG

1шт.

58

1305 531 H1

NUT

1шт.

59

1211 267 H1

NUT

1шт.

N/I

1223 266 H91

PACKAGE, BUSHING REPAIR

1шт.

N/I

1223 267 H91

PACKAGE, SHIFT LEVER REPAIR

1шт.

N/I

1223 268 H91

PACKAGE, BRUSH REPAIR

1шт.

N/I

1223 269 H91

PACKAGE, SERVICE

1шт.

|$$79

-1шт.

|$79

F1 - PART OF PACKAGE 1223 266 H91.

-1шт.

|$$81

-1шт.

|$$82

-1шт.

|$82

F2 - PART OF PACKAGE 1223 267 H91.

-1шт.

|$$84

-1шт.

|$$85

-1шт.

|$85

F3 - PART OF PACKAGE 1223 268 H91.

-1шт.

|$$87

-1шт.

|$$88

-1шт.

|$88

F4 - PACKAGE CONSISTS OF (NON-SERVICE PARTS):

-1шт.

|$89

1 BUSHING, 3 INSULATORS AND AN INSTRUCTION SHEET

-1шт.
