Запчасти Komatsu WA450-2 FIG NO. ЭЛЕКТРИКА - ЗАДН. LIGHT ЛИНИЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

1

LIGHT ASSEMBLY, L.H. REAR COMBINATION

-1шт.

|$1

(SEE PG 01-094)

1шт.

2

LIGHT ASSEMBLY, R.H. REAR COMBINATION

-1шт.

|$3

(SEE PG 01-096)

1шт.

3

01580-10504

NUT

8шт.

4

01641-20508

WASHER

8шт.

5

421-06-13440

BRACKET, LIGHT - L.H

1шт.

6

01435-01025

BOLT

4шт.

7

424-06-14191

PLATE

2шт.

8

01435-01020

BOLT

4шт.

9

LIGHT ASSEMBLY, REAR WORK (SEE PG 01-098)

-29шт.

10

421-06-12123

HARNESS, WIRING

1шт.

11

08052-01911

CLIP

1шт.

12

421-06-12910

CLIP

1шт.

13

01220-40608

SCREW

2шт.

14

01641-20608

WASHER

2шт.

15

421-06-12131

HARNESS, WIRING

1шт.

16

419-06-A1180

ALARM, BACK-UP

a

1шт.

|$18

419-06-A1190

ALARM, BACK-UP

b

1шт.

|$19

01220-40408

SCREW, SOUND POSITION

3шт.

|$20

01370-00408

SCREW, COVER MOUNTING

4шт.

|$21

08021-00400

CONNECTOR

1шт.

|$22

08031-10210

TERMINAL, RING GROUND

1шт.

N/I

6132-11-6460

BOLT, ALARM MOUNTING

2шт.

N/I

01640-20816

WASHER, ALARM MOUNTING

2шт.

17

08036-10814

CLIP

1шт.

18

08036-01414

CLIP

2шт.

19

01010-81016

BOLT

3шт.

20

01643-31032

WASHER

3шт.

21

08036-10810

CLIP

1шт.

22

01435-00812

BOLT

1шт.

23

421-06-13450

BRACKET, LIGHT - R.H

1шт.

24

HARNESS, WIRING - REAR FRAME LINE (SEE PG 01-084)

-29шт.

|$70

-1шт.

|$34

F1 - SERVICE PARTS FOR WIRING HARNESS 421-06-12123

-1шт.

|$71

-1шт.

|$36

HARNESS, WIRING

1шт.

|$37

283-06-16410

CONNECTOR - AT REAR FRAME HARNESS

1шт.

|$38

421-09-11620

CONNECTOR - AT REAR WORK LIGHT HARNESS

1шт.

|$39

421-09-11650

TERMINAL - AT REAR WORK LIGHT HARNESS

2шт.

|$40

582-06-11930

TERMINAL - AT REAR FRAME HARNESS

4шт.

|$41

582-06-11960

CONNECTOR - AT COOLANT LEVEL SENSOR IN RADIATOR

1шт.

|$42

7816-14-1550

TERMINAL - AT COOLANT LEVEL SENSOR IN RADIATOR

1шт.

|$43

07000-02016

O-RING - AT REAR FRAME HARNESS

1шт.

|$44

08022-04001

CONNECTOR - AT BACK-UP ALARM AND

-1шт.

|$45

REAR PLATE LIGHT

2шт.

|$46

08021-00400

CONNECTOR - AT REAR FRAME HARNESS

1шт.

|$47

08031-10210

TERMINAL - AT BACK-UP ALARM

1шт.

|$72

-1шт.

|$49

F2 - SERVICE PARTS FOR WIRING HARNESS 421-06-12131

-1шт.

|$73

-1шт.

|$51

HARNESS, WIRING

1шт.

|$52

421-09-11150

CONNECTOR - AT REAR WORK LIGHTS

2шт.

|$53

421-09-11250

TERMINAL - AT REAR WORK LIGHTS

4шт.

|$54

421-09-11520

CONNECTOR - AT RADIATOR GUARD HARNESS

1шт.

|$55

421-09-11550

TERMINAL - AT RADIATOR GUARD HARNESS

2шт.

|$74

-1шт.

|$57

F3 - SERVICE PARTS FOR BACK-UP ALARM 419-06-A1180

-1шт.

|$75

-1шт.

|$59

ALARM, BACK-UP

1шт.

|$60

419-06-A1200

CABLE, POSITIVE

1шт.

|$61

419-06-A1210

CABLE, NEGATIVE

1шт.

|$62

737 188 C2

ALARM

1шт.

|$76

-1шт.

|$64

F4 - SERVICE PARTS FOR BACK-UP ALARM 419-06-A1190

-1шт.

|$77

-1шт.

|$66

ALARM, BACK-UP

1шт.

|$67

419-06-A1200

CABLE, POSITIVE

1шт.

|$68

419-06-A1210

CABLE, NEGATIVE

1шт.

|$69

736 131 C2

ALARM

1шт.
