Запчасти Komatsu WA450-2 ТЕРМОСТАТ СИСТЕМА ОХЛАЖДЕНИЯ

|$0

1246 511 H91

HOUSING, THERMOSTAT

1шт.

1

NSS

HOUSING, THERMOSTAT

1шт.

2

1238 500 H1

SEAL, THERMOSTAT

1шт.

3

1240 101 H1

PLUG, PIPE (1/8 NPT)

1шт.

4

6732-11-1910

PLUG, PIPE (1/2 NPT)

2шт.

5

6732-11-1920

PLUG, PIPE (3/4 NPT)

1шт.

6

1277 844 H91

SUPPORT, THERMOSTAT HOUSING

1шт.

7

1296 841 H1

GASKET, THERMOSTAT HOUSING

1шт.

8

1277 843 H1

HOSE, PLAIN

1шт.

9

1246 515 H2

BOLT (M10x1.50x145)

2шт.

10

1246 517 H3

GASKET, SUPPORT

1шт.

|$11

1246 118 H91

PLUG, THREADED (9/16-18 UNF)

1шт.

11

1246 119 H1

O-RING

1шт.

12

NSS

PLUG, THREADED (9/16-18 INCH)

1шт.

13

1240 426 H1

CLAMP, HOSE

2шт.

14

1294 287 H1

BOLT (M10x1.50x35)

4шт.

15

1307 094 H1

BOLT (M10x1.50x170)

2шт.

16

6732-21-5540

PLUG, PIPE (3/8 NPT)

1шт.

17

1313 015 H1

THERMOSTAT

1шт.

|$$20

-1шт.

|$20

F1 - REQUIRED ONLY IF MACHINE DOES NOT HAVE AIR COMPRESSOR

-1шт.

|$$22

-1шт.
