Запчасти Komatsu WA450-2 FIG NO. ЭЛЕКТРИКА - ЗАДН. РАМА ЛИНИЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА
№
Артикул
Название
Примечание
Количество
1
421-06-18380
HARNESS, WIRING
1шт.
2
421-06-12830
HARNESS, WIRING
1шт.
4
421-06-12851
HARNESS, WIRING
1шт.
5
01435-00608
BOLT
1шт.
6
08052-02711
CLIP
1шт.
7
08052-02411
CLIP
1шт.
8
08052-01711
CLIP
7шт.
9
01220-40608
SCREW
10шт.
11
419-09-11160
CLIP
1шт.
19
HARNESS, WIRING - REAR LIGHT (SEE PG 01-090)
-29шт.
20
SENSOR, FUEL LEVEL (SEE PG 01-042)
-29шт.
21
TANK, AIR (SEE PG 03-056)
-29шт.
22
BRACKET (SEE PG 01-072)
-29шт.
23
TANK, WINDOW WASHER (SEE PG 05-126)
-29шт.
24
CHAMBER ASSEMBLY, BRAKE (SEE PG 03-086)
-29шт.
25
RELAY, BATTERY (SEE PG 01-088)
-29шт.
26
BREAKER, MAIN CIRCUIT (SEE PG 01-080)
-29шт.
27
HARNESS, WIRING - ENGINE LINE (SEE PG 01-080)
-29шт.
28
421-06-12840
HARNESS, AIR DRYER WIRING
1шт.
|$28
08021-00400
CONNECTOR, MALE
1шт.
|$29
08022-04001
CONNECTOR, FEMALE
2шт.
29
DRYER ASSEMBLY, AIR (SEE PG 03-076)
-29шт.
|$96
-1шт.
|$32
F1 - SERVICE PARTS FOR WIRING HARNESS 421-06-18380
-1шт.
|$97
-1шт.
|$34
HARNESS, WIRING
1шт.
|$35
421-09-11650
TERMINAL, WIRE
4шт.
|$36
421-09-11420
CONNECTOR - AT DIODE
2шт.
|$38
418-06-11360
CONNECTOR - AT ETHER START SOLENOID
1шт.
|$39
22X-06-16130
CONNECTOR - AT POWER SUPPLY
1шт.
|$40
22X-06-16120
CONNECTOR - AT POWER SUPPLY
1шт.
|$41
08050-12720
CONNECTOR - AT FLOOR HARNESS
1шт.
|$42
08050-12300
GROMMET - AT FLOOR HARNESS
3шт.
|$43
08050-12200
O-RING - AT ENGINE HARNESS
1шт.
|$44
08050-12120
CONNECTOR - AT FLOOR HARNESS
1шт.
|$45
08050-12110
BODY, CONNECTOR - AT FLOOR HARNESS
1шт.
|$46
08050-12010
CONNECTOR - AT ENGINE HARNESS
1шт.
|$47
08050-08300
GROMMET - AT BULK HEAD HARNESS
1шт.
|$48
08050-08200
O-RING - AT BULK HEAD HARNESS
1шт.
|$49
08050-08010
BODY, CONNECTOR - AT BULK HEAD HARNESS
1шт.
|$50
08050-04810
CONNECTOR - AT REAR LAMP HARNESS
1шт.
|$51
08050-03810
CONNECTOR - AT BATTERY RELAY
2шт.
|$52
08050-02820
CONNECTOR - AT BRAKE SWITCH
1шт.
|$53
08050-02810
BODY, CONNECTOR - AT AIR PRESSURE AND FUEL
-1шт.
|$54
LEVEL SENSORS
2шт.
|$55
08050-00600
PLUG
10шт.
|$56
08050-00500
TERMINAL, FEMALE
18шт.
|$57
08050-00400
TERMINAL, MALE
16шт.
|$59
08031-11508
TERMINAL - AT BATTERY RELAY
1шт.
|$60
08031-11506
TERMINAL - AT MAIN CIRCUIT BREAKER
1шт.
|$61
08031-10806
TERMINAL - AT MAIN CIRCUIT BREAKER
2шт.
|$62
08031-10210
TERMINAL - AT RIGHT BATTERY NEGATIVE TERMINAL
-1шт.
|$63
AND GROUND CONNECTION
2шт.
|$64
08027-11660
CONNECTOR - AT REAR COMBINATION LIGHTS
2шт.
|$65
08022-04001
CONNECTOR - AT AIR DRYER HEATER AND
-1шт.
|$66
BACK-UP ALARM
2шт.
|$98
-1шт.
|$68
F2 - SERVICE PARTS FOR WIRING HARNESS 421-06-12830
-1шт.
|$99
-1шт.
|$70
HARNESS, WIRING
1шт.
|$71
22W-07-11850
CONNECTOR - AT REAR FRAME HARNESS
1шт.
|$72
22W-07-11890
CAP
1шт.
|$73
22W-07-11910
O-RING
1шт.
|$74
421-09-11160
CONNECTOR - AT BATTERY RELAY
1шт.
|$75
421-09-11260
TERMINAL, BLADE - AT BATTERY RELAY
1шт.
|$76
582-06-11930
TERMINAL - AT REAR FRAME HARNESS
3шт.
|$77
08031-10204
TERMINAL, RING - AT BATTERY RELAY
1шт.
|$78
08031-10208
TERMINAL, RING - AT BATTERY RELAY
1шт.
|$100
-1шт.
|$80
-1шт.
|$101
-1шт.
|$82
F3 - SERVICE PARTS FOR WIRING HARNESS 421-06-12851
-1шт.
|$102
-1шт.
|$84
HARNESS, WIRING
1шт.
|$86
421-09-11420
CONNECTOR - AT DIODE
1шт.
|$87
421-09-11650
TERMINAL - AT DIODE
1шт.
|$88
08050-08110
CONNECTOR - AT REAR FRAME HARNESS
1шт.
|$89
08050-08300
GROMMET - AT REAR FRAME HARNESS
1шт.
|$90
08050-00500
TERMINAL - AT REAR FRAME HARNESS
6шт.
|$91
08027-11260
CONNECTOR - AT WASHER TANKS
2шт.
|$92
08050-02810
BODY, CONNECTOR - AT WHEEL BRAKE CHAMBER SENSOR
2шт.
|$93
08031-10106
TERMINAL - AT GROUND CONNECTION
1шт.
|$94
08031-10208
TERMINAL - AT GROUND CONNECTION
1шт.
Выбрано товаров: 96
