Запчасти Komatsu WA450-2 FIG NO. ЭЛЕКТРИКА - ЛИНИЯ ДВИГАТЕЛЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

1

421-06-18332

HARNESS, WIRING

1шт.

2

418-06-A1170

HARNESS, STARTER DISABLE RELAY WIRING

1шт.

3

08034-00536

BAND

14шт.

4

391-62-19240

CLAMP, HARNESS AND CABLE

a

2шт.

4

421-07-11550

CLIP

b

2шт.

5

01010-81016

BOLT

1шт.

6

01643-31032

WASHER

1шт.

7

SENSOR, COOLANT TEMPERATURE (SEE PG 01-004)

-29шт.

8

08038-02027

CAP

1шт.

9

08038-00519

CAP

1шт.

10

421-06-11440

BREAKER, MAIN CIRCUIT

1шт.

11

01435-00616

BOLT

2шт.

12

08034-00823

BAND

3шт.

13

ALTERNATOR ASSEMBLY (SEE PG 01-020)

-29шт.

14

HARNESS, WIRING - REAR FRAME LINE (SEE PG 01-084)

-29шт.

15

SENSOR ASSEMBLY, ENGINE OIL LEVEL

-1шт.

|$16

(SEE PG 01-030)

1шт.

16

MOTOR ASSEMBLY, CRANKING (SEE PG 01-014)

-29шт.

17

SOLENOID, FUEL SHUT-OFF VALVE (SEE PG 01-014)

-29шт.

18

SWITCH, ENGINE OIL PRESSURE (SEE PG 01-004)

-29шт.

19

RELAY, STARTER DISABLE (SEE PG 01-004)

-29шт.

|$45

-1шт.

|$22

F1 - SERVICE PARTS FOR WIRING HARNESS 421-06-18332

-1шт.

|$46

-1шт.

|$24

HARNESS, WIRING

1шт.

|$25

418-06-11310

CONNECTOR - AT ENGINE COOLANT TEMPERATURE SENSOR

1шт.

|$26

418-06-11320

CONNECTOR - AT ALTERNATOR RELAY TERMINAL

1шт.

|$27

418-06-11330

CONNECTOR - AT ENGINE OIL PRESSURE SWITCH

1шт.

|$28

418-06-11340

TERMINAL - AT ENGINE OIL PRESSURE SWITCH AND

-1шт.

|$29

COOLANT TEMPERATURE SENSOR

4шт.

|$30

421-06-11970

DIODE

3шт.

|$31

421-09-11420

CONNECTOR - AT DIODE

3шт.

|$32

421-09-11650

TERMINAL - AT DIODE

6шт.

|$33

423-06-11730

CONNECTOR - AT ENGINE OIL LEVEL SENSOR

1шт.

|$34

08031-10210

TERMINAL - AT GROUND CONNECTION

1шт.

|$35

08031-10510

TERMINAL - AT FUEL SHUT-OFF SOLENOID

1шт.

|$36

08031-11506

TERMINAL - AT MAIN CIRCUIT BREAKER R TERMINAL

-1шт.

|$37

AND ALTERNATOR BATTERY AND GROUND TERMINALS

3шт.

|$38

08031-11510

TERMINAL - AT GROUND CONNECTION

1шт.

|$39

08034-00414

BAND - AT DIODE

2шт.

|$40

08050-03810

CONNECTOR - AT STARTER SWITCH

1шт.

|$41

08050-12110

BODY, CONNECTOR - AT REAR FRAME HARNESS

1шт.

|$42

08050-12300

GROMMET - AT REAR FRAME HARNESS

1шт.

|$43

08050-00500

TERMINAL - AT REAR FRAME HARNESS

10шт.

|$44

08050-00600

PLUG - AT REAR FRAME HARNESS

2шт.
