Запчасти Komatsu WA450-2 ПОРШЕНЬ И ШАТУН БЛОК ЦИЛИНДРОВ

|$0

1246 413 H93

KIT, ENGINE PISTON

6шт.

1

NSS

PISTON, ENGINE

1шт.

2

1246 416 H1

RING, RETAINING

2шт.

3

1246 415 H1

PIN, PISTON

1шт.

|$4

1304 748 H91

SET, PISTON RING

6шт.

4

1296 503 H1

RING, OIL (OIL RING)

1шт.

5

1296 502 H2

RING, COMPRESSION (2ND RING)

1шт.

6

1296 501 H1

RING, COMPRESSION (TOP RING)

1шт.

|$8

1280 654 H93

ROD ASSEMBLY, CONNECTING

6шт.

7

NSS

ROD, CONNECTING

1шт.

8

1294 171 H1

BUSHING

1шт.

9

1246 410 H1

DOWEL, RING

2шт.

10

1246 411 H1

BOLT (M14x1.50x91)

2шт.

|$30

-1шт.

|$14

CONNECTING ROD BEARINGS

-1шт.

11

1246 412 H1

BEARING, CONNECTING ROD - STD

12шт.

|$16

1246 635 H1

BEARING, CONNECTING ROD - 0.25 MM O/S

12шт.

|$17

1246 636 H1

BEARING, CONNECTING ROD - 0.50 MM O/S

12шт.

|$18

1246 637 H1

BEARING, CONNECTING ROD - 0.75 MM O/S

12шт.

|$19

1246 638 H1

BEARING, CONNECTING ROD - 1.00 MM O/S

12шт.

|$20

1304 749 H91

KIT, CYLINDER

6шт.

|$21

NSS

LINER, CYLINDER

1шт.

|$22

NSS

PISTON, ENGINE

1шт.

|$23

1246 164 H1

O-RING

1шт.

|$24

1246 415 H1

PIN, PISTON

1шт.

|$25

1246 416 H1

RING, RETAINING

1шт.

|$26

1304 748 H91

SET, PISTON RING

6шт.

|$27

1296 503 H1

RING, OIL (OIL RING)

1шт.

|$28

1296 502 H2

RING, COMPRESSION (2ND RING)

1шт.

|$29

1296 501 H1

RING, COMPRESSION (TOP RING)

1шт.
