Запчасти Komatsu WA450-2 FIG NO. 98A PROВОЗДУХОВОДЫ GRAPHICS - ИСПАНИЯ МАРКИРОВКАS, ИНСТРУМЕНТ & КОМПЛЕКТS

1

421-93-A1180

PLATE, CAUTION BATTERY

1шт.

2

1132 722 C2

PRODUCT GRAPHIC, CAUTION PRESSURE COOLING SYSTEM

1шт.

3

644 865 C3

PRODUCT GRAPHIC, CAUTION HYDRAULIC OIL TANK

1шт.

4

417-V00-1210

PLATE, CAUTION BATTERY

1шт.

5

421-93-12750

PLATE, MARK - WA450

1шт.

6

421-54-A1350

PLATE, STRIPE

1шт.

7

1124 685 C2

PRODUCT GRAPHIC, IMPORTANT DIESEL FUEL

1шт.

8

419-V00-1140

PLATE, ENGINE FAN CAUTION

2шт.

9

1132 016 C2

PRODUCT GRAPHIC, ENGINE OIL DRAIN

1шт.

10

09690-C0224

PLATE, MARK - KOMATSU

2шт.

11

421-54-A1350

PLATE, STRIPE

1шт.

12

421-93-12750

PLATE, MARK - WA450

1шт.

13

09152-01000

PLATE, CAUTION AIR TANK DRAIN

3шт.

14

419-V00-1230

PLATE, DANGER ARTICULATION

2шт.

15

419-V00-1130

PLATE, CAUTION FRAME LOCK BAR

1шт.

16

419-V00-1160

PLATE, CAUTION TRANSMISSION OIL LEVEL

1шт.

17

421-V00-1111

CHART, OIL

1шт.

18

938 944 C2

PRODUCT GRAPHIC, RADIATOR DRAIN

1шт.

19

421-V00-1250

PLATE, REMOTE GREASE - TORQUE CONVERTER MOUNTING

1шт.

20

421-93-12220

PLATE, REMOTE GREASE - REAR AXLE TRUNNION

1шт.

21

09690-C0400

PLATE, MARK - KOMATSU

1шт.

22

09685-00003

PLATE, OPERATING LEVER LOCK

1шт.

23

421-93-A1160

PLATE, CAUTION BATTERY CHARGING

2шт.

24

421-93-11132

PLATE, OPERATING BUCKET CONTROL LEVER

1шт.

25

421-V00-1220

PLATE, OPERATING RELAY

1шт.

26

421-V00-1230

PLATE, FUSE BOX

1шт.

27

421-V00-1240

PLATE, FUSE BOX

1шт.

28

09683-11070

PLATE, OPERATING STARTING SWITCH

1шт.

29

419-V00-1150

SAFETY PRECAUTIONS

1шт.

30

423-V00-1131

PLATE, CAUTION STARTING

1шт.

31

427-V00-1130

PLATE, CAUTION TRANSMISSION OIL LEVEL

1шт.

32

NSS

PLATE, PRODUCT IDENTIFICATION

1шт.

|$32

04418-13060

SCREW

4шт.

33

421-V00-1260

PLATE, P.P.C. PIPING

1шт.

34

939 372 C3

PRODUCT GRAPHIC, LADDER CAUTION

1шт.

35

1120 095 C2

PRODUCT GRAPHIC, LIFT AND TIE DOWN HERE

4шт.

36

423-V00-1180

PLATE, AIR DRYER CAUTION

1шт.

N/I

09637-30161

PLATE, AIR CLEANER

-1шт.

|$38

(END OF AIR CLEANER, INSIDE COVER)

1шт.

N/I

737 993 C3

CAUTION, ROLLOVER

1шт.

N/I

1170 724 C1

PLATE, EMERGENCY EXIT

1шт.

37

421-54-A1340

PLATE, STRIPE TOP

1шт.

38

421-54-A1320

PLATE, STRIPE - L.H

1шт.

39

421-54-A1330

PLATE, STRIPE - R.H

1шт.

40

421-93-A1110

PLATE, IMPORTANT ETHER START

1шт.
