Запчасти Komatsu WA450-2 FIG NO. ЭЛЕКТРИКА - ЛЕВ. КОНСОЛЬ ДЛЯ MACHINES EQUIPPED С КАБИНОЙ - заводской номер A7 И UP КОМПОНЕНТЫ ДВИГАТЕЛЯ & ЭЛЕКТРИКА

1

421-06-12581

HARNESS, WIRING

1шт.

2

RELAY, AIR CONDITIONER (SEE PG 05-148)

-29шт.

3

421-06-A1120

SWITCH, FRONT WIPER

1шт.

4

421-06-A1130

SWITCH, REAR WIPER

1шт.

5

08036-01814

CLIP

1шт.

6

01010-81020

BOLT

1шт.

7

01643-31032

WASHER

1шт.

8

08036-10814

CLIP

1шт.

9

01010-81020

BOLT

1шт.

10

01643-31032

WASHER

1шт.

11

421-06-A1140

WIRE, FUSE BOX TO FRONT WIPER SWITCH

1шт.

12

421-06-A1150

CONNECTOR, WIRE - AT FUSE BOX

1шт.

|$$13

-1шт.

|$13

F1 - SERVICE PARTS FOR WIRING HARNESS 421-06-12581

-1шт.

|$$15

-1шт.

|$15

HARNESS, WIRING

1шт.

|$16

08021-00400

CONNECTOR - AT RADIO SPEAKER

1шт.

|$17

08022-04001

CONNECTOR - AT RADIO POWER SOURCE AND SPEAKER

2шт.

|$18

08027-02000

TERMINAL - AT REAR WIPER, CAB DOME LIGHT, CAB

-1шт.

|$$20

-1шт.

|$20

MOUNTED WORK LIGHT AND RADIO SPEAKER CONNECTORS . 10

-1шт.

|$21

08027-00620

CONNECTOR - FOR REAR WIPER AND CAB DOME LIGHT

1шт.

|$22

08027-00420

CONNECTOR - FOR CAB MOUNTED WORK LIGHT AND RADIO

-1шт.

|$23

SPEAKER

1шт.

|$24

421-09-11640

CONNECTOR - FOR REAR WIPER SWITCH

1шт.

|$25

421-09-11650

TERMINAL - AT FRONT AND REAR WIPER

-1шт.

|$26

SWITCH CONNECTORS

9шт.

|$27

421-09-11660

CONNECTOR - FOR FRONT WIPER SWITCH

1шт.

|$28

582-06-11930

TERMINAL - AT FLOOR HARNESS CONNECTOR

12шт.

|$29

22W-07-11980

CONNECTOR - AT FLOOR HARNESS

1шт.

|$30

22W-07-11990

CAP - AT FLOOR HARNESS CONNECTOR

1шт.

|$31

22W-07-12110

O-RING - AT FLOOR HARNESS CONNECTOR

1шт.

|$32

08027-11310

CONNECTOR - AT FLOOR HARNESS

1шт.

|$33

08036-41210

CLIP

1шт.
