Запчасти Komatsu WA450-2 FIG NO. 8 КАБИНА ЭЛЕКТР. ЭЛЕКТРОПРОВОДКА РАМА, ЧАСТИ КОРПУСА & SUPERSTRUCTURE

|$16

CAB, OPERATOR'S (SEE PG 05-068)

-1шт.

|$17

CAB, OPERATOR'S (SEE PG 05-072)

-1шт.

|$18

CAB, OPERATOR'S (SEE PG 05-076)

-1шт.

|$0

CAB, OPERATOR'S (SEE PG 05-080)

-29шт.

|$19

CAB, INTERNAL (SEE PG 05-084)

-1шт.

|$20

CAB, INTERNAL (SEE PG 05-088)

-1шт.

|$1

CAB, INTERNAL (SEE PG 05-092)

-29шт.

|$2

421-925-A131

CAB WIRING

1шт.

1

421-925-A410

HOSE, FRONT WASHER

1шт.

2

421-925-A450

HOSE, REAR WASHER

1шт.

3

421-925-A460

HARNESS, CAB FRONT

1шт.

4

421-925-A470

HARNESS, CAB REAR

1шт.

5

421-925-A560

CLIP, HARNESS

7шт.

6

421-09-A1270

GROMMET

1шт.

7

421-09-A1280

GROMMET

1шт.

8

421-925-A160

CLIP, HARNESS

3шт.

9

GROMMET (SEE PG 05-068)

-29шт.

9

GROMMET (SEE PG 05-072)

-1шт.

9

GROMMET (SEE PG 05-076)

-1шт.

9

GROMMET (SEE PG 05-080)

-1шт.

|$23

-1шт.

|$13

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE

-1шт.

|$14

ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.
