Запчасти Komatsu WA450-2 FIG NO. B КАБИНА - РЕВЕРС POLARITY ДВОРНИКИ МОТОРS КАБИНА MODEL NO. CB - ПЕРЕДН. ДВОРНИКИ РАМА, ЧАСТИ КОРПУСА & SUPERSTRUCTURE

|$0

CAB, OPERATORS (SEE PG 05-072)

-29шт.

|$1

421-925-A201

KIT, FRONT WIPER

1шт.

1

421-925-AC30

MOTOR, WIPER

1шт.

|$3

421-925-A250

PIVOT ASSEMBLY, ARM

1шт.

2

NSS

GASKET, PIVOT

1шт.

3

NSS

PIVOT, ARM

1шт.

4

NSS

NUT, ARM - PIVOT

1шт.

5

421-925-A220

ARM, WIPER

1шт.

6

421-925-A230

BLADE, WIPER

1шт.

7

421-925-AC50

WASHER, FLAT

1шт.

8

421-925-AC60

GASKET

1шт.

9

421-925-AC80

NUT, HEX

1шт.

10

426-09-11140

NUT, HEX

1шт.

11

421-925-AD60

SEAL, WEATHER

1шт.

12

COVER, FRONT MOUNTING (SEE PG 05-072)

-29шт.

|$37

-1шт.

|$16

F1 - FOR COMPLETE REPLACEMENT OF FRONT WIPER MOTOR KIT, ORDER THE

-1шт.

|$17

FOLLOWING PARTS:

-1шт.

|$18

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$19

421-925-AC71

COVER, FRONT MOUNTING

1шт.

|$38

-1шт.

|$21

F2 - WITH WIPER ARM RETAINED WITH NUTS, ORDER THE FOLLOWING PARTS:

-1шт.

|$39

-1шт.

|$23

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$24

421-925-AC71

COVER, FRONT MOUNTING

1шт.

|$40

-1шт.

|$26

-1шт.

|$41

-1шт.

|$28

F3 - 25.4 MM (1.00 IN) BETWEEN WIPER ARM MOUNTS ON PIVOT, ORDER THE

-1шт.

|$29

FOLLOWING PARTS:

-1шт.

|$30

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$31

421-925-AC71

COVER, FRONT MOUNTING

1шт.

|$42

-1шт.

|$33

F4 - USED WITH PIVOT ASSEMBLY WITH 25.4MM (1.00 IN) BETWEEN WIPER ARM

-1шт.

|$34

MOUNTS, ORDER THE FOLLOWING PARTS:

-1шт.

|$35

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$36

421-925-AC71

COVER, FRONT MOUNTING

1шт.
