Запчасти Komatsu WA450-2 FIG NO. A КАБИНА - СТАНДАРТН. POLARITY ДВОРНИКИ МОТОРS КАБИНА MODEL NO. CA - ПЕРЕДН. ДВОРНИКИ РАМА, ЧАСТИ КОРПУСА & SUPERSTRUCTURE

|$0

CAB, OPERATORS (SEE PG 05-068)

-29шт.

|$1

421-925-A200

KIT, FRONT WIPER

1шт.

1

421-925-A210

MOTOR, WIPER

1шт.

|$3

421-925-A250

PIVOT ASSEMBLY, ARM

1шт.

2

NSS

GASKET, PIVOT

1шт.

3

NSS

PIVOT, ARM

1шт.

4

NSS

NUT, ARM - PIVOT

1шт.

|$7

421-925-A240

KIT, HARDWARE

1шт.

5

NSS

NUT, ARM - MOTOR

1шт.

6

NSS

SPACER, ARM

1шт.

7

NSS

SEAL, WEATHER

1шт.

8

NSS

NUT, MOTOR

1шт.

9

421-925-A220

ARM, WIPER

1шт.

10

421-925-A230

BLADE, WIPER

1шт.

11

COVER, FRONT MOUNTING (SEE PG 05-068)

-29шт.

N/I

PIVOT ASSEMBLY, ARM (SEE PG 05-116)

-29шт.

|$33

-1шт.

|$17

F1 - FOR COMPLETE REPLACEMENT OF FRONT WIPER MOTOR KIT, ORDER THE

-1шт.

|$18

FOLLOWING PARTS.

-1шт.

|$19

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$20

421-925-AC71

COVER, FRONT MOUNTING

1шт.

|$34

-1шт.

|$22

F2 - 25.4MM (1.00 IN) BETWEEN WIPER ARM MOUNTS ON PIVOT, ORDER THE

-1шт.

|$23

FOLLOWING PARTS.

-1шт.

|$24

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$25

421-925-AC71

COVER, FRONT MOUNTING

1шт.

|$35

-1шт.

|$27

F3 - USED WITH PIVOT ASSEMBLY WITH 25.4 MM (1.00 IN) BETWEEN WIPER

-1шт.

|$28

ARM MOUNTS, ORDER THE FOLLOWING PARTS.

-1шт.

|$29

421-925-A203

KIT, FRONT WIPER - REVERSE POLARITY

1шт.

|$30

421-925-AC71

COVER, FRONT MOUNTING

1шт.

|$36

-1шт.

|$32

F4 - 35.8 MM (1.40 IN) BETWEEN WIPER ARM MOUNTS ON PIVOT.

-1шт.

|$37

-1шт.
