Запчасти Komatsu WA430-6E0 ТРАНСМИССИЯ (1 И 4 МУФТА) F ТРАНСМИССИЯ

|$1

424-15-H1062

TRANSMISSION ASSEMBLY

SN: H60613-UP

1шт.

|$2

424-15-H1061

TRANSMISSION ASSEMBLY

SN: H60557-H60612

1шт.

|$3

424-15-H1060

TRANSMISSION ASSEMBLY

SN: H60266-H60556

1шт.

|$4

424-15-H1052

TRANSMISSION ASSEMBLY, WITH LOCK UP

SN: .-UP

1шт.

|$5

424-15-H1050

TRANSMISSION ASSEMBLY, WITH LOCK UP

SN: H60266-.

1шт.

|$6

714-17-32021

CLUTCH, 1ST AND 4TH

SN: H60266-UP

1шт.

1

714-17-32121

SHAFT, 1ST AND 4TH

SN: H60266-UP

1шт.

|$8

0

SHAFT, UPPER

SN: H60266-UP

1шт.

|$9

0

HOUSING

SN: H60266-UP

1шт.

|$10

0

ORIFICE

SN: H60266-UP

1шт.

|$11

0

BALL

SN: H60266-UP

2шт.

2

714-07-22661

PISTON, RANGE

SN: H60266-UP

2шт.

3

714-12-19711

DISK

SN: H60266-UP

12шт.

4

714-16-19730

PLATE, SEPARATE

SN: H60266-UP

14шт.

5

56D-15-12710

RING

SN: H60266-UP

12шт.

6

714-12-12610

PLATE, END

SN: H60266-UP

2шт.

7

419-15-12140

RING, SNAP

SN: H60266-UP

2шт.

8

714-16-19220

RING, SEAL

SN: H60266-UP

2шт.

9

714-07-19320

RING, SEAL

SN: H60266-UP

2шт.

10

714-08-19570

WASHER, THRUST

SN: H60266-UP

3шт.

11

714-08-19560

WASHER

SN: H60266-UP

1шт.

12

714-23-19410

BEARING, NEEDLE

SN: H60266-UP

2шт.

13

714-23-19430

BEARING, NEEDLE

SN: H60266-UP

1шт.

14

714-11-12720

SHIM

SN: H60266-UP

1шт.

15

714-07-22550

RING

SN: H60266-UP

1шт.

16

714-12-22441

GEAR, 4TH

SN: H60266-UP

1шт.

17

714-24-22430

GEAR, 1ST

SN: H60266-UP

1шт.

18

714-24-22510

GEAR, 2ND

SN: H60266-UP

1шт.

19

714-07-29320

BEARING

SN: H60266-UP

1шт.

20

714-12-19340

BEARING

SN: H60266-UP

1шт.

21

419-15-12122

SEAL

SN: H60266-UP

3шт.
