Запчасти Komatsu WA430-6 HD-КОВШ .CBM (. M) (KVX-СИСТЕМА) T РАБОЧЕЕ ОБОРУДОВАНИЕ

1

423-72-H2680

BUCKET

SN: H60051-UP

1шт.

2

421-71-H2650

BLADE, RHS, (WELDED)

SN: H60051-UP

1шт.

3

421-71-H2660

BLADE, LHS, (WELDED)

SN: H60051-UP

1шт.

4

423-71-H2F70

REINFORCEMENT, RHS, (WELDED)

SN: H60051-UP

1шт.

5

423-71-H2F80

REINFORCEMENT, LHS, (WELDED)

SN: H60051-UP

1шт.

6

423-71-H2F90

PLATE, (WELDED)

SN: H60051-UP

2шт.

7

423-71-H2G00

PLATE, (WELDED)

SN: H60051-UP

5шт.

8

423-70-H2C20

PLATE, (WELDED)

SN: H60051-UP

2шт.

9

424-70-H2B20

PLATE, (WELDED)

SN: H60051-UP

1шт.

10

423-71-H2J30

SKID, (WELDED)

SN: H60051-UP

2шт.

11

423-70-H2410

SKID, (WELDED)

SN: H60051-UP

4шт.

12

0

KVX - SYSTEM

SN: H60051-UP

1шт.

13

421-75-H2460

BLADE, (WELDED)

SN: H60051-UP

1шт.

14

421-75-H2410

TOOTH, RHS

SN: H60051-UP

1шт.

15

421-75-H2430

TOOTH

SN: H60051-UP

6шт.

16

421-75-H2400

TOOTH, LHS

SN: H60051-UP

1шт.

17

421-75-H2470

PLATE

SN: H60051-UP

7шт.

18

421-75-H2450

BOLT

SN: H60051-UP

23шт.
