Запчасти Komatsu WA430-6 U-A МАРКИРОВКА (/) МАРКИРОВКА

|$0

423-93-41311

OIL CHART

1шт.

1

NSS

PLATE, REMOTE GREASE, CYLINDER

1шт.

2

NSS

PLATE, REMOTE GREASE, REAR AXLE

1шт.

3

NSS

PLATE, RADIATOR DRAIN

1шт.

4

NSS

PLATE, ENGINE OIL DRAIN

1шт.

5

NSS

PLATE

1шт.

6

NSS

PLATE

1шт.

7

09805-03000

PLATE, SAFETY (NEVER BE ON THIS HOOD)

2шт.

8

424-93-41161

OIL CHART

1шт.

9

424-93-41110

PLATE, MARK, WA430 (L.H.)

1шт.

10

424-93-41120

PLATE, MARK, WA430 (R.H.)

1шт.

11

423-93-41130

PLATE, L.H.

1шт.

12

423-93-41140

PLATE, R.H.

1шт.

13

09690-P0710

PLATE, MARK

2шт.

14

09812-13000

PLATE, SAFETY (KEEP A SAFE DISTANCE)

2шт.

15

09807-C0883

PLATE, SAFETY (KEEP OUT)

2шт.

16

09960-01601

PLATE, MARK (LIFT HERE)

4шт.

17

09669-0000E

PLATE, CAUTION (DIESEL FUEL)

1шт.

18

09659-53000

PLATE, SAFETY (PPC ACCUMULATOR)

1шт.

19

09659-53000

PLATE, SAFETY (BRAKE ACCUMULATOR)

2шт.

20

09659-53000

PLATE, SAFETY (ECSS ACCUMULATOR)

1шт.

21

09602-15040

PLATE, NAME (USA ONLY)

1шт.

|$42

OR

22

-1шт.

21

09602-10041

PLATE, NAME

1шт.

22

04418-13060

SCREW

4шт.

23

09685-00004

PLATE, OPERATING, LOCK LEVER

1шт.

24

09667-03001

PLATE, SAFETY (FAN BELT)

1шт.

25

09667-03001

PLATE, SAFETY (FAN BELT)

2шт.

26

09161-23000

PLATE, FRAME LOC

1шт.

27

09162-23000

PLATE, ARTICULATE

2шт.

28

09653-03001

PLATE, SAFETY (RADIATOR CAP)

1шт.

29

09668-03001

PLATE, SAFETY (HYDRAULIC TANK CAP)

1шт.

30

09808-03000

PLATE, SAFETY (ELECTRIC SHOCK)

2шт.

31

09664-30011

SAFETY PLATE ASSEMBLY, BATTERY

2шт.

32

20Y-00-41530

PLATE, MARK, ECOT 3

1шт.

33

20Y-00-41340

PLATE, PREFILTER CAUTION

1шт.

34

14X-98-35181

PLATE, REFLECTOR

2шт.

35

424-93-41230

PLATE, POSITION OF CONNECTOR

1шт.

36

09690-P0500

DECAL, CAB DOOR (KOMATSU)

2шт.

37

425-93-A1100

DECAL, FRONT WINDOW

1шт.

38

423-93-23410

PLATE, HOOD

2шт.

39

423-93-23420

PLATE, HOOD

1шт.

|$43

42

-1шт.

|$44

F2 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

44

-1шт.

|$45

F2 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

44

-1шт.
