Запчасти Komatsu WA430-6 H-A ГИДР. НАСОС. ПОГРУЗ. НАСОС (/) ГИДРАВЛИКА

|$22

PUMP ASSEMBLY, LOADER (SEE FIG. H0210-01A0) .PUMP SUBASSEMBLY (SEE FIG. H0210-10A0 )

0

-1шт.

|$1

PUMP SUBASSEMBLY (SEE FIG. H0210-10A0A )

SN: A42001-A42023-UP

-1шт.

1

07000-13040

O-RING

1шт.

2

07000-B2014

O-RING

3шт.

3

07000-B1009

O-RING

2шт.

4

708-2L-25480

FILTER, HYDRAULIC PUMP

3шт.

5

04020-00616

PIN, DOWEL

2шт.

6

01252-60640

BOLT

4шт.

7

20B-27-11210

BLEEDER

1шт.

|$9

708-1W-03920

BLOCK ASSEMBLY

1шт.

|$10

708-1W-04590

BLOCK SUBASSEMBLY

1шт.

8

NSS

BLOCK

1шт.

9

708-21-12541

PLUG

1шт.

10

708-1W-04580

VALVE ASSEMBLY, SHUTTLE

1шт.

11

708-7R-18230

FILTER

1шт.

12

07002-61423

O-RING

1шт.

13

07000-B1009

O-RING

1шт.

14

01252-60830

BOLT

2шт.

15

07000-B1009

O-RING

2шт.

16

723-46-16780

ORIFICE

SN: A42024--UP

1шт.

17

708-8E-16160

PLUG

SN: A42024--UP

1шт.

18

07002-11023

O-RING

SN: A42024--UP

1шт.

|$23

22

-1шт.

|$24

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

23

-1шт.
