Запчасти Komatsu WA430-6 H-A ГИДР. НАСОС. ПОГРУЗ. НАСОС (/) ГИДРАВЛИКА

|$30

PUMP ASSEMBLY, LOADER (SEE FIG. H0210-01A0) .PUMP SUBASSEMBLY (SEE FIG. H0210-10A0 )

0

-1шт.

|$1

PUMP SUBASSEMBLY (SEE FIG. H0210-10A0A )

SN: A42001-A42023-UP

-1шт.

1

708-1W-43110

BLOCK, CYLINDER

SN: A42024--UP

1шт.

|$31

OR

3

-1шт.

1

708-1W-43310

BLOCK, CYLINDER

SN: A42001-A42023-UP

1шт.

2

708-1W-43230

PLATE, VALVE

SN: A42024--UP

1шт.

|$32

OR

6

-1шт.

2

708-1W-43210

PLATE, VALVE

SN: A42001-A42023-UP

1шт.

3

720-68-19610

PIN

1шт.

4

708-1W-43130

SEAT

2шт.

5

708-1W-43140

SPRING

1шт.

6

04065-04818

RING, SNAP

1шт.

7

708-1W-43350

GUIDE, RETAINER

1шт.

8

708-3T-13360

PIN

3шт.

9

708-1W-43320

RETAINER, SHOE

1шт.

|$33

OR

15

-1шт.

9

708-1W-43341

RETAINER, SHOE

1шт.

10

708-1U-13310

PISTON SUBASSEMBLY

9шт.

11

708-1W-44170

PISTON

SN: A42024--UP

1шт.

|$34

OR

19

-1шт.

11

NSS

PISTON

SN: A42006-A42023-UP

1шт.

|$35

OR

21

-1шт.

11

708-1W-44120

PISTON SUBASSEMBLY

SN: A42001-A42005-UP

1шт.

12

708-1W-44140

SPRING

SN: A42024--UP

1шт.

|$36

OR

24

-1шт.

12

708-3T-14120

SPRING

SN: A42001-A42023-UP

1шт.

13

708-1U-14240

SCREW

2шт.

14

07000-12011

O-RING

2шт.

15

01643-31232

WASHER

2шт.

16

01582-11210

NUT

2шт.

|$37

30

-1шт.

|$38

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBU TORS ONLY.

31

-1шт.
