Запчасти Komatsu WA430-6 H-8A ГИДР. НАСОС. ВЕНТИЛЯТОР (/) ГИДРАВЛИКА

|$33

PUMP, FAN ( SEE FIG. H0210-01A0 )

0

-1шт.

|$34

.PUMP SUBASSEMBLY ( SEE FIG. H0210-08A0 )

1

-1шт.

1

708-1S-12320

SHAFT

1шт.

2

706-73-40890

BEARING, ROLLER

1шт.

3

708-1S-12260

BEARING

1шт.

4

708-7T-05020

SPACER KIT

1шт.

|$6

708-7T-12260

SPACER, 1.6 MM

1шт.

|$7

708-7T-12270

SPACER, 1.7 MM

1шт.

|$8

708-7T-12360

SPACER, 1.8 MM

1шт.

|$9

708-7T-12370

SPACER, 1.9 MM

1шт.

|$10

708-7T-12380

SPACER, 2.0 MM

1шт.

|$11

708-7T-12390

SPACER, 2.1 MM

1шт.

|$12

708-7T-12460

SPACER, 2.2 MM

1шт.

5

708-1S-12280

RING, WIRE

1шт.

6

708-1S-12330

RETAINER

1шт.

7

708-1S-12340

CASE

1шт.

8

708-1T-11880

SEAL, OIL

1шт.

9

207-09-11140

O-RING

1шт.

10

04065-06220

RING

1шт.

11

708-1S-13130

BLOCK, CYLINDER

1шт.

12

708-1S-13450

PLATE, VALVE

1шт.

13

708-3S-13160

WASHER

2шт.

14

708-3S-13150

SPRING

1шт.

15

04065-03515

RING, SNAP

1шт.

16

708-1S-13370

GUIDE, RETAINER

1шт.

17

708-1S-13380

PIN

3шт.

18

708-1S-13360

RETAINER, SHOE

1шт.

19

708-1S-13320

PISTON SUBASSEMBLY

7шт.

20

708-1S-14210

PLUG

1шт.

21

708-3S-14261

PLUG

1шт.

22

07002-11223

O-RING

2шт.

23

708-1S-14230

PISTON SUBASSEMBLY

1шт.

24

708-1S-14241

SPRING

1шт.

|$35

33

-1шт.

|$36

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DIS TRIBUTORS ONLY.

34

-1шт.
