Запчасти Komatsu WA430-6 U-A МАРКИРОВКА (/) МАРКИРОВКА

|$0

423-93-41152

PLATE

SN: A41001--UP

1шт.

1

NSS

PLATE, MAIN SWITCH

SN: A41001--UP

1шт.

2

NSS

PLATE, WORK EQUIPMENT LEVER LOCK

SN: A41001--UP

1шт.

3

NSS

PLATE, WORK EQUIPMENT PATTERN

SN: A41001--UP

1шт.

4

NSS

PLATE, RELAY

SN: A41001--UP

1шт.

5

NSS

PLATE, FUSE (2)

SN: A41001--UP

1шт.

6

NSS

PLATE, FUSE (1)

SN: A41001--UP

1шт.

7

NSS

PLATE, AIR CONDITIONER FILTER

SN: A41001--UP

1шт.

8

09802-33000

PLATE, SAFETY (SAFETY CONFIRM OF REAR)

SN: A41001--UP

1шт.

9

22U-00-21510

PLATE

SN: A41001--UP

1шт.

10

09651-03001

PLATE, SAFETY (READ OPERATION MANUAL)

SN: A41001--UP

1шт.

11

09654-03001

PLATE, SAFETY (SUDDEN START)

SN: A41001--UP

1шт.

12

09801-13001

PLATE, SAFETY (ELECTRIC SHOCK)

SN: A41001--UP

1шт.

13

09963-03001

TAG

SN: A41001--UP

1шт.

14

09845-00480

DECAL, KOMTRAX BLAST ZONE WARNING

1шт.

|$14

14

-1шт.

|$15

F1 - CANNOT BE SUPPLIED AS AN INDIVIDUAL PART; IT IS SUPPLIED AS AN ASSEMBLY.

15

-1шт.
