Запчасти Komatsu WA430-6 H-A ГИДР. НАСОС. ГИДРОТРАНСФОРМАТОР ГИДРАВЛИКА

|$0

PUMP ASSEMBLY, TORQUE CONVERTER (SEE FIG. H0210-01A0)

SN: A41001--UP

-1шт.

1

NSS

BRACKET

SN: A41001--UP

1шт.

N/I

NSS

BUSHING, PLANE

SN: A41001--UP

2шт.

2

NSS

CASE, GEAR

SN: A41001--UP

1шт.

3

NSS

CARRIER ASSEMBLY

SN: A41001--UP

1шт.

N/I

NSS

CARRIER

SN: A41001--UP

1шт.

N/I

NSS

BUSHING

SN: A41001--UP

2шт.

4

NSS

CARRIER

SN: A41001--UP

1шт.

N/I

NSS

BUSHING, PLANE

SN: A41001--UP

2шт.

5

NSS

GEAR, DRIVE

SN: A41001--UP

1шт.

6

NSS

GEAR, DRIVE

SN: A41001--UP

1шт.

7

705-17-03630

PLATE, SIDE

SN: A41001--UP

1шт.

8

705-17-03640

PLATE, SIDE

SN: A41001--UP

1шт.

9

705-17-03443

RING, BACK-UP

SN: A41001--UP

2шт.

10

705-17-03473

SEAL, RING

SN: A41001--UP

2шт.

11

705-17-03381

O-RING

SN: A41001--UP

3шт.

12

04020-01228

PIN, DOWEL

SN: A41001--UP

6шт.

13

01253-61645

BOLT

SN: A41001--UP

4шт.

14

01643-51645

WASHER

SN: A41001--UP

4шт.

15

705-17-03870

PLATE

SN: A41001--UP

1шт.

16

705-17-03811

SEAL, OIL

SN: A41001--UP

1шт.

17

04065-05220

RING, SNAP

SN: A41001--UP

1шт.

18

01252-61450

BOLT

SN: A41001--UP

4шт.

19

705-17-04980

WASHER

SN: A41001--UP

4шт.

|$24

24

-1шт.

|$25

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

25

-1шт.
