Запчасти Komatsu WA430-6 H-9A ГИДР. НАСОС. РУЛЕВ. УПРАВЛЕНИЕ (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY, STEERING (SEE FIG. H0210-01A0)

SN: A41024--UP

-1шт.

|$1

PUMP ASSEMBLY, STEERING (SEE FIG. H0210-01A0)

SN: A41001-A41023-UP

-1шт.

|$2

PUMP SUBASSEMBLY (SEE FIG. H0210-09A0B)

SN: A41024--UP

-1шт.

|$3

PUMP SUBASSEMBLY (SEE FIG. H0210-09A0C)

SN: A41001-A41023-UP

-1шт.

1

NSS

O-RING

SN: A41001--UP

1шт.

2

07000-B2014

O-RING

SN: A41001--UP

2шт.

3

07000-B1009

O-RING

SN: A41001--UP

2шт.

4

NSS

FILTER, HYDRAULIC PUMP

SN: A41001--UP

2шт.

5

NSS

PIN, DOWEL

SN: A41001--UP

2шт.

6

NSS

BOLT

SN: A41001--UP

3шт.

7

NSS

BOLT

SN: A41001--UP

1шт.

8

20B-27-11210

BLEEDER

SN: A41001--UP

1шт.

|$12

12

-1шт.

|$13

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

13

-1шт.
