Запчасти Komatsu WA430-6 F-A ТРАНСМИССИЯ 2 И 3 МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

TRANSMISSION (SEE FIG. F4350-51A0 )

SN: A41001--UP

-1шт.

|$1

714-24-22032

CLUTCH, 2ND AND 3RD

SN: A41001--UP

1шт.

1

714-24-22132

SHAFT, 2ND AND 3RD

SN: A41001--UP

1шт.

2

714-07-22661

PISTON, RANGE

SN: A41001--UP

1шт.

3

714-23-12690

PISTON, RANGE

SN: A41001--UP

1шт.

4

714-12-19711

DISC

SN: A41001--UP

14шт.

5

714-16-19730

PLATE, SEPARATE

SN: A41001--UP

16шт.

6

56D-15-12710

SPRING, WAVE

SN: A41001--UP

14шт.

7

714-12-12610

PLATE, END

SN: A41001--UP

2шт.

8

419-15-12140

RING, SNAP

SN: A41001--UP

2шт.

9

714-16-19220

RING, SEAL

SN: A41001--UP

2шт.

10

714-07-19320

RING, SEAL

SN: A41001--UP

2шт.

11

714-08-19570

WASHER, THRUST

SN: A41001--UP

4шт.

12

714-23-19430

BEARING, NEEDLE

SN: A41001--UP

2шт.

13

714-24-22460

GEAR, 2ND

SN: A41001--UP

1шт.

14

714-12-22451

GEAR, 40 TEETH, 3RD

SN: A41001--UP

1шт.

15

714-24-22531

GEAR, OUTPUT

SN: A41001--UP

1шт.

16

714-12-22541

GEAR, 28 TEETH, 4TH

SN: A41001--UP

1шт.

17

14X-14-19123

BEARING

SN: A41001--UP

1шт.

18

714-07-29350

BEARING

SN: A41001--UP

1шт.

19

419-15-12122

RING

SN: A41001--UP

3шт.

|$21

713-15-05040

SERVICE KIT, TRANSMISSION

SN: A41001--UP

1шт.

|$22

22

-1шт.

|$23

F1 - PART INCLUDED IN SERVICE KIT:

23

-1шт.
