Запчасти Komatsu WA430-6 F-A ТРАНСМИССИЯ 1 И 4 МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

TRANSMISSION (SEE FIG. F4350-51A0 )

SN: A41001--UP

-1шт.

|$1

714-17-32021

CLUTCH, 1ST AND 4TH

SN: A41001--UP

1шт.

1

714-17-32121

SHAFT, 1ST AND 4TH

SN: A41001--UP

1шт.

2

714-07-22661

PISTON, RANGE

SN: A41001--UP

2шт.

3

714-12-19711

DISC

SN: A41001--UP

12шт.

4

714-16-19730

PLATE, SEPARATE

SN: A41001--UP

14шт.

5

56D-15-12710

SPRING, WAVE

SN: A41001--UP

12шт.

6

714-12-12610

PLATE, END

SN: A41001--UP

2шт.

7

419-15-12140

RING, SNAP

SN: A41001--UP

2шт.

8

714-16-19220

RING, SEAL

SN: A41001--UP

2шт.

9

714-07-19320

RING, SEAL

SN: A41001--UP

2шт.

10

714-08-19570

WASHER, THRUST

SN: A41001--UP

3шт.

11

714-08-19560

WASHER, THRUST

SN: A41001--UP

1шт.

12

714-23-19410

BEARING, NEEDLE

SN: A41001--UP

2шт.

13

714-23-19430

BEARING, NEEDLE

SN: A41001--UP

1шт.

14

714-11-12720

SPACER

SN: A41001--UP

1шт.

15

714-07-22550

RING, SNAP

SN: A41001--UP

1шт.

16

714-12-22441

GEAR, 31 TEETH, 4TH

SN: A41001--UP

1шт.

17

714-24-22430

GEAR, 1ST

SN: A41001--UP

1шт.

18

714-24-22510

GEAR, 2ND

SN: A41001--UP

1шт.

19

714-07-29320

BEARING

SN: A41001--UP

1шт.

20

714-12-19340

BEARING, ROLLER

SN: A41001--UP

1шт.

21

419-15-12122

RING, SEAL

SN: A41001--UP

3шт.

|$23

714-15-05040

SERVICE KIT, TRANSMISSION

SN: A41001--UP

1шт.

|$24

24

-1шт.

|$25

F1 - PART INCLUDED IN SERVICE KIT:

25

-1шт.
