Запчасти Komatsu WA430-6 ТРАНСМИССИЯ (2 И 3 МУФТА)(№-) СИЛОВАЯ ПЕРЕДАЧА

|$4

714-17-30003

TRANSMISSION ASS'Y

SN: 65499-UP

1шт.

|$5

714-17-30002

TRANSMISSION ASS'Y

SN: 65360-65498

1шт.

|$6

714-17-30001

TRANSMISSION ASS'Y

SN: 65185-65359

1шт.

|$7

714-17-30000

TRANSMISSION ASS'Y

SN: 65001-65184

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-64A0.

-1шт.

|$15

714-24-22032

CLUTCH,2ND AND 3RD

SN: 65001-UP

1шт.

1

714-24-22132

SHAFT,2ND AND 3RD

SN: 65001-UP

1шт.

1

0

SHAFT,LOWER

SN: 65001-UP

1шт.

1

0

ORIFICE

SN: 65001-UP

1шт.

1

0

BALL

SN: 65001-UP

2шт.

1

0

HOUSING

SN: 65001-UP

1шт.

1

0

SCREW

SN: 65001-UP

1шт.

2

714-07-22661

PISTON,RANGE

SN: 65001-UP

1шт.

3

714-23-12690

PISTON,RANGE

SN: 65001-UP

1шт.

4

714-12-19711

DISC

SN: 65001-UP

14шт.

5

714-16-19730

PLATE,SEPARATE

SN: 65001-UP

16шт.

6

56D-15-12710

SPRING,WAVE

SN: 65001-UP

14шт.

7

714-12-12610

PLATE,END

SN: 65001-UP

2шт.

8

419-15-12140

RING,SNAP

SN: 65001-UP

2шт.

9

714-16-19220

RING

SN: 65001-UP

2шт.

10

714-07-19320

RING,SEAL (K1)

SN: 65001-UP

2шт.

11

714-08-19570

WASHER,THRUST

SN: 65001-UP

4шт.

12

714-23-19430

BEARING,NEEDLE

SN: 65001-UP

2шт.

13

714-24-22460

GEAR, 53 TEETH,2ND

SN: 65001-UP

1шт.

14

714-12-22451

GEAR, 40 TEETH,3RD

SN: 65001-UP

1шт.

15

714-24-22531

GEAR, 50 TEETH,OUTPUT

SN: 65001-UP

1шт.

16

714-12-22541

GEAR, 28 TEETH,4TH

SN: 65001-UP

1шт.

17

14X-14-19123

BEARING

SN: 65001-UP

1шт.

18

714-07-29350

BEARING

SN: 65001-UP

1шт.

19

419-15-12122

RING (K1)

SN: 65001-UP

3шт.
