Запчасти Komatsu WA430-6 ТРАНСМИССИЯ (1 И 4 МУФТА)(№-) СИЛОВАЯ ПЕРЕДАЧА

|$4

714-17-30003

TRANSMISSION ASS'Y

SN: 65499-UP

1шт.

|$5

714-17-30002

TRANSMISSION ASS'Y

SN: 65360-65498

1шт.

|$6

714-17-30001

TRANSMISSION ASS'Y

SN: 65185-65359

1шт.

|$7

714-17-30000

TRANSMISSION ASS'Y

SN: 65001-65184

1шт.

|$$5

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-64A0.

-1шт.

|$15

714-17-32021

CLUTCH,1ST AND 4TH

SN: 65001-UP

1шт.

1

714-17-32121

SHAFT,1ST AND 4TH

SN: 65001-UP

1шт.

1

0

SHAFT,UPPER

SN: 65001-UP

1шт.

1

0

HOUSING

SN: 65001-UP

1шт.

1

0

ORIFICE

SN: 65001-UP

1шт.

1

0

BALL

SN: 65001-UP

2шт.

2

714-07-22661

PISTON,RANGE

SN: 65001-UP

2шт.

3

714-12-19711

DISC

SN: 65001-UP

12шт.

4

714-16-19730

PLATE,SEPARATE

SN: 65001-UP

14шт.

5

56D-15-12710

SPRING,WAVE

SN: 65001-UP

12шт.

6

714-12-12610

PLATE,END

SN: 65001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 65001-UP

2шт.

8

714-16-19220

RING

SN: 65001-UP

2шт.

9

714-07-19320

RING,SEAL (K1)

SN: 65001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 65001-UP

3шт.

11

714-08-19560

WASHER

SN: 65001-UP

1шт.

12

714-23-19410

BEARING,NEEDLE

SN: 65001-UP

2шт.

13

714-23-19430

BEARING,NEEDLE

SN: 65001-UP

1шт.

14

714-11-12720

SPACER

SN: 65001-UP

1шт.

15

714-07-22550

SNAP RING

SN: 65001-UP

1шт.

16

714-12-22441

GEAR, 64 TEETH,4TH

SN: 65001-UP

1шт.

17

714-24-22430

GEAR, 26 TEETH,1ST

SN: 65001-UP

1шт.

18

714-24-22510

GEAR, 37 TEETH,2ND

SN: 65001-UP

1шт.

19

714-07-29320

BEARING

SN: 65001-UP

1шт.

20

714-12-19340

BEARING

SN: 65001-UP

1шт.

21

419-15-12122

RING (K1)

SN: 65001-UP

3шт.
