Запчасти Komatsu WA430-5-SN МОДУЛИРУЮЩИЙ КЛАПАН ТРАНСМИССИЯ
№
Артикул
Название
Примечание
Количество
|1
714-17-20000
TRANSMISSION ASS'Y,(STD)
SN: 60001-UP
1шт.
|1
714-17-20010
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 60001-UP
1шт.
|1
714-17-20100
TRANSMISSION ASS'Y,(FOR TACHOGRAPH)
SN: 60001-UP
1шт.
|1
714-17-20110
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)
SN: 60001-UP
1шт.
|1
714-17-20300
TRANSMISSION ASS'Y,(COLD TERRAIN SPEC.)
SN: 60001-UP
1шт.
|1
714-17-20310
TRANSMISSION ASS'Y,(WITH LOCK-UP) (COLD)
SN: 60001-UP
1шт.
|1
714-17-20400
TRANSMISSION ASS'Y,(FOR TACHOGRAPH) (COLD)
SN: 60001-UP
1шт.
|1
714-17-20410
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND L/C) (C)
SN: 60001-UP
1шт.
|$$9
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|1
714-17-25000
VALVE ASS'Y
SN: 60001-UP
1шт.
|1
714-17-25010
VALVE ASS'Y,(WITH LOCK-UP)
SN: 60001-UP
1шт.
|1
714-12-25002
VALVE ASS'Y,(COLD TERRAIN SPEC.)
SN: 60001-UP
1шт.
|1
714-12-25012
VALVE ASS'Y,(WITH LOCK-UP) (COLD)
SN: 60001-UP
1шт.
|1
714-17-26001
VALVE ASS'Y
SN: 60007-UP
1шт.
|1
0
VALVE ASS'Y
SN: 60001-60006
1шт.
|1
714-07-26000
VALVE ASS'Y,(COLD TERRAIN SPEC.)
SN: 60001-UP
1шт.
1
17A-15-25131
BODY
SN: 60001-UP
1шт.
3
14X-15-15850
PLUG
SN: 60001-UP
1шт.
5
714-07-25230
VALVE
SN: 60007-UP
1шт.
12
426-15-15810
PLUG
SN: 60001-UP
1шт.
18
14X-15-16210
SPRING
SN: 60001-UP
1шт.
20
14X-15-15850
PLUG
SN: 60001-UP
2шт.
Выбрано товаров: 39
