Запчасти Komatsu WA430-5 КЛАПАН КОНТРОЛЯ ПОТОКА ТРАНСМИССИИ ТРАНСМИССИЯ

|1

714-17-20000

TRANSMISSION ASS'Y,(STD)

SN: 60001-UP

1шт.

|1

714-17-20010

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 60001-UP

1шт.

|1

714-17-20100

TRANSMISSION ASS'Y,(FOR TACHOGRAPH)

SN: 60001-UP

1шт.

|1

714-17-20110

TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)

SN: 60001-UP

1шт.

|1

714-17-20300

TRANSMISSION ASS'Y,(COLD TERRAIN SPEC.)

SN: 60001-UP

1шт.

|1

714-17-20310

TRANSMISSION ASS'Y,(WITH LOCK-UP) (COLD)

SN: 60001-UP

1шт.

|1

714-17-20400

TRANSMISSION ASS'Y,(FOR TACHOGRAPH) (COLD)

SN: 60001-UP

1шт.

|1

714-17-20410

TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND L/C) (C)

SN: 60001-UP

1шт.

|$$9

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

1

714-17-25401

VALVE ASS'Y

SN: 60021-UP

1шт.

|1

714-17-25400

VALVE ASS'Y

SN: 60001-60020

1шт.

|1

714-07-25461

BODY

SN: 60021-UP

1шт.

|1

714-07-25460

BODY

SN: 60001-60020

1шт.

1

714-07-25151

BODY

SN: 60021-UP

1шт.

|1

714-07-25150

BODY

SN: 60001-60020

1шт.

2

07042-80108

PLUG

SN: 60021-UP

2шт.

|2

07043-70108

PLUG

SN: 60001-60020

2шт.

3

714-07-15410

VALVE

SN: 60001-UP

1шт.

4

714-07-15420

SPRING

SN: 60001-UP

1шт.

5

714-12-15430

CHOKE

SN: 60001-UP

1шт.

6

714-07-15840

COVER

SN: 60001-UP

2шт.

7

01010-80820

BOLT

SN: 60001-UP

4шт.

8

01643-30823

WASHER

SN: 60001-UP

4шт.

9

07000-73030

O-RING (K2)

SN: 60001-UP

2шт.
