Запчасти Komatsu WA430-5 ТРАНСМИССИЯ (УПРАВЛЯЮЩ. КЛАПАН И КРЕПЛЕНИЕ) ТРАНСМИССИЯ

|1

714-17-20000

TRANSMISSION ASS'Y,(STD)

SN: 60001-UP

1шт.

|1

714-17-20010

TRANSMISSION ASS'Y,(WITH LOCK-UP)

SN: 60001-UP

1шт.

|1

714-17-20100

TRANSMISSION ASS'Y,(FOR TACHOGRAPH)

SN: 60001-UP

1шт.

|1

714-17-20110

TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)

SN: 60001-UP

1шт.

|1

714-17-20300

TRANSMISSION ASS'Y,(COLD TERRAIN SPEC.)

SN: 60001-UP

1шт.

|1

714-17-20310

TRANSMISSION ASS'Y,(WITH LOCK-UP) (COLD)

SN: 60001-UP

1шт.

|1

714-17-20400

TRANSMISSION ASS'Y,(FOR TACHOGRAPH) (COLD)

SN: 60001-UP

1шт.

|1

714-17-20410

TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND L/C) (C)

SN: 60001-UP

1шт.

|$$9

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

1

714-17-25401

VALVE ASS'Y

SN: 60021-UP

1шт.

|1

714-17-25400

VALVE ASS'Y

SN: 60001-60020

1шт.

|1

714-17-25600

VALVE ASS'Y,(COLD TERRAIN SPEC.)

SN: 60001-UP

1шт.

2

01252-31065

BOLT

SN: 60001-UP

1шт.

3

01252-31055

BOLT

SN: 60001-UP

3шт.

4

07000-73040

O-RING (K1)

SN: 60001-UP

1шт.

5

714-17-25000

VALVE ASS'Y

SN: 60001-UP

1шт.

|5

714-17-25010

VALVE ASS'Y,(WITH LOCK-UP)

SN: 60001-UP

1шт.

|5

714-12-25002

VALVE ASS'Y,(COLD TERRAIN SPEC.)

SN: 60001-UP

1шт.

|5

714-12-25012

VALVE ASS'Y,(WITH LOCK-UP) (COLD)

SN: 60001-UP

1шт.

6

01010-81055

BOLT

SN: 60001-UP

6шт.

7

01643-31032

WASHER

SN: 60001-UP

6шт.

8

01011-81020

BOLT

SN: 60001-UP

1шт.

9

01643-31032

WASHER

SN: 60001-UP

1шт.

10

01011-81005

BOLT

SN: 60001-UP

2шт.

11

01643-31032

WASHER

SN: 60001-UP

2шт.

12

01011-81010

BOLT

SN: 60001-UP

1шт.

13

01643-31032

WASHER

SN: 60001-UP

1шт.

14

07000-73028

O-RING (K1)

SN: 60001-UP

3шт.

15

07000-72015

O-RING (K1)

SN: 60001-UP

25шт.

16

07000-72012

O-RING (K1)

SN: 60001-UP

2шт.

17

07000-73045

O-RING (K1)

SN: 60001-UP

1шт.
