Запчасти Komatsu WA430-5 ТРАНСМИССИЯ (1 И 4 МУФТА) ТРАНСМИССИЯ
№
Артикул
Название
Примечание
Количество
|1
714-17-20000
TRANSMISSION ASS'Y,(STD)
SN: 60001-UP
1шт.
|1
714-17-20010
TRANSMISSION ASS'Y,(WITH LOCK-UP)
SN: 60001-UP
1шт.
|1
714-17-20100
TRANSMISSION ASS'Y,(FOR TACHOGRAPH)
SN: 60001-UP
1шт.
|1
714-17-20110
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND LOCK-UP)
SN: 60001-UP
1шт.
|1
714-17-20300
TRANSMISSION ASS'Y,(COLD TERRAIN SPEC.)
SN: 60001-UP
1шт.
|1
714-17-20310
TRANSMISSION ASS'Y,(WITH LOCK-UP) (COLD)
SN: 60001-UP
1шт.
|1
714-17-20400
TRANSMISSION ASS'Y,(FOR TACHOGRAPH) (COLD)
SN: 60001-UP
1шт.
|1
714-17-20410
TRANSMISSION ASS'Y,(FOR TACHOGRAPH AND L/C) (C)
SN: 60001-UP
1шт.
|$$9
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|1
714-12-22020
CLUTCH,1ST AND 4TH
SN: 60001-UP
1шт.
1
714-12-22121
SHAFT AND CYLINDER A,1ST AND 4TH
SN: 60001-UP
1шт.
|1
0
SHAFT,UPPER
SN: 60001-UP
1шт.
|1
0
HOUSING
SN: 60001-UP
1шт.
|1
0
ORIFICE
SN: 60001-UP
1шт.
|1
0
BALL
SN: 60001-UP
2шт.
2
714-07-22661
PISTON,RANGE
SN: 60001-UP
2шт.
14
714-11-12720
SPACER
SN: 60001-UP
1шт.
15
714-07-22550
SNAP RING
SN: 60001-UP
1шт.
16
714-12-22441
GEAR¤ 31 TEETH,4TH
SN: 60001-UP
1шт.
17
714-12-22431
GEAR¤ 26 TEETH,1ST
SN: 60001-UP
1шт.
18
714-12-22511
GEAR¤ 37 TEETH,2ND
SN: 60001-UP
1шт.
20
714-12-29340
BEARING
SN: 60001-UP
1шт.
Выбрано товаров: 35
