Запчасти Komatsu WA430-5 КАБИНА ROPS (РАДИО COVER) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

423-926-3010

ROPS CAB ASS'Y

SN: 60001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A5.

-1шт.

|1

423-926-3020

ROPS CAB ASS'Y,(E)

SN: 60001-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A6.

-1шт.

|1

423-926-3030

ROPS CAB ASS'Y,(A)

SN: 60001-UP

1шт.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A7.

-1шт.

|1

423-926-3040

ROPS CAB ASS'Y,(A+E)

SN: 60001-UP

1шт.

|$$8

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-24A1.

-1шт.

|$$9

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

|$$10

A = AIR CONDITIONER

-1шт.

|$$11

E = LOAD METER

-1шт.

1

421-925-3510

COVER,RADIO

SN: 60001-UP

1шт.

2

01023-60412

SCREW

SN: 60001-UP

2шт.

3

01640-20408

WASHER

SN: 60001-UP

2шт.

4

01580-00403

NUT

SN: 60001-UP

2шт.

5

421-06-36141

SWITCH

SN: 60001-UP

1шт.

6

42C-56-12310

CAP

SN: 60001-UP

7шт.
