|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$9
714-17-20003
TRANSMISSION ASS'Y
SN: (110604)-UP
1шт.
|$10
714-17-20002
TRANSMISSION ASS'Y
SN: 60001-(110603)
1шт.
|$11
0
TRANSMISSION ASS'Y
SN: (60001-(110185))
1шт.
|$12
0
TRANSMISSION ASS'Y
SN: (60001-(110179))
1шт.
|$13
714-17-20303
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: (110604)-UP
1шт.
|$14
714-17-20302
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: 60001-(110603)
1шт.
|$15
0
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: (60001-(110185))
1шт.
|$16
0
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: (60001-(110179))
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.
-1шт.
|$18
714-17-20013
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: (110604)-UP
1шт.
|$19
714-17-20012
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: 60001-(110603)
1шт.
|$20
0
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: (60001-(110185))
1шт.
|$21
0
TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)
SN: (60001-(110179))
1шт.
|$22
714-17-20313
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (110604)-UP
1шт.
|$23
714-17-20312
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: 60001-(110603)
1шт.
|$24
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (60001-(110185))
1шт.
|$25
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (60001-(110179))
1шт.
|$$19
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.
-1шт.
1
56D-15-19311
STRAINER
SN: 61254-UP
1шт.
1
0
STRAINER
SN: 60001-61253
1шт.
2
07000-15085
O-RING (K1)
SN: 60001-UP
1шт.
3
714-07-28100
ELBOW
SN: 60001-UP
2шт.
4
02896-61018
O-RING
SN: (110604)-UP
2шт.
4
02896-11018
O-RING (K1)
SN: 60001-(110603)
2шт.
5
07040-11007
PLUG
SN: 60001-UP
2шт.
6
07002-61023
O-RING (K1)
SN: (110604)-UP
2шт.
6
07002-11023
O-RING (K1)
SN: 60001-(110603)
2шт.
7
07002-63334
O-RING (K1)
SN: (110604)-UP
2шт.
7
07002-13334
O-RING (K1)
SN: 60001-(110603)
2шт.
8
714-07-28703
FILTER ASS'Y
SN: (110626)-UP
1шт.
8
714-07-28702
FILTER ASS'Y
SN: 60001-(110625)
1шт.
8
714-07-28713
CARTRIDGE
SN: (110626)-UP
1шт.
8
714-07-28712
CARTRIDGE
SN: 60001-(110625)
1шт.
9
01010-81030
BOLT
SN: (110186)-UP
3шт.
9
01010-81030
BOLT
SN: 60001-(110185)
4шт.
10
01643-31032
WASHER
SN: (110186)-UP
3шт.
10
01643-31032
WASHER
SN: 60001-(110185)
4шт.
11
714-12-28752
SUPPORT
SN: (110186)-UP
1шт.
11
714-12-28751
SUPPORT
SN: 60001-(110186)
1шт.
12
01010-81230
BOLT
SN: 60001-UP
3шт.
13
01643-31232
WASHER
SN: 60001-UP
3шт.
14
714-07-28811
HOSE
SN: (110604)-UP
1шт.
14
714-07-28810
HOSE
SN: 60007-(110603)
1шт.
14
02763-00610
HOSE
SN: 60001-60006
1шт.
15
04434-52511
CLIP
SN: 60001-UP
1шт.
16
01010-81020
BOLT
SN: 60001-UP
1шт.
17
01643-31032
WASHER
SN: 60001-UP
1шт.
18
02782-10628
ELBOW
SN: 60001-UP
1шт.
19
02896-61018
O-RING (K1)
SN: (110604)-UP
1шт.
19
02896-11018
O-RING (K1)
SN: 60001-(110603)
1шт.
20
07002-62434
O-RING (K1)
SN: (110604)-UP
1шт.
20
07002-12434
O-RING (K1)
SN: 60001-(110603)
1шт.
21
714-12-28820
HOSE
SN: (110186)-UP
1шт.
21
714-12-28790
HOSE
SN: 60007-(110185)
1шт.
21
02762-006A9
HOSE
SN: 60001-60006
1шт.
22
04434-52511
CLIP
SN: 60001-UP
1шт.
23
01010-81020
BOLT
SN: 60001-UP
1шт.
24
01643-31032
WASHER
SN: 60001-UP
1шт.
25
01010-81225
BOLT
SN: 60001-UP
1шт.
26
01643-31232
WASHER
SN: 60001-UP
1шт.
27
04434-52512
CLIP
SN: 60001-UP
1шт.
28
02781-00628
UNION
SN: 60001-UP
1шт.
29
02896-61018
O-RING (K1)
SN: (110604)-UP
1шт.
29
02896-11018
O-RING (K1)
SN: 60001-(110603)
1шт.
30
07002-62434
O-RING (K1)
SN: (110604)-UP
1шт.
30
07002-12434
O-RING (K1)
SN: 60001-(110603)
1шт.
31
714-12-28890
TUBE
SN: 60001-UP
1шт.
32
07206-30710
BOLT
SN: 60001-UP
3шт.
33
07005-01012
SEAL, WASHER (K1)
SN: 60001-UP
6шт.
34
04434-50610
CLIP
SN: 60001-UP
2шт.
35
01010-81020
BOLT
SN: 60001-UP
2шт.
36
01643-31032
WASHER
SN: 60001-UP
2шт.
37
21W-62-42490
ELBOW
SN: 60001-UP
1шт.
38
02896-11009
O-RING (K1)
SN: 60001-UP
1шт.
39
07002-11423
O-RING (K1)
SN: 60001-UP
1шт.
40
20U-62-41710
NIPPLE
SN: 60001-UP
1шт.
41
02896-11009
O-RING (K1)
SN: 60001-UP
1шт.
42
07002-11423
O-RING (K1)
SN: 60001-UP
1шт.
43
714-12-28771
HOSE
SN: (110604)-UP
1шт.
43
714-12-28770
HOSE
SN: (110186)-(110603)
1шт.
43
02766-00305
HOSE
SN: 60001-(110185)
1шт.
44
714-07-28780
TUBE
SN: (110186)-UP
1шт.
45
04434-51610
CLIP
SN: 60001-UP
1шт.
46
01010-81020
BOLT
SN: 60001-UP
1шт.
47
01643-31032
WASHER
SN: 60001-UP
1шт.
48
01010-81045
BOLT
SN: (110186)-UP
1шт.
49
01643-31032
WASHER
SN: (110186)-UP
1шт.
50
6166-73-2290
SPACER
SN: (110186)-UP
1шт.
51
08193-21012
CLIP
SN: (110186)-UP
1шт.
52
01435-01016
BOLT
SN: (110186)-UP
1шт.
53
04434-52711
CLIP
SN: (110186)-UP
1шт.
54
01435-01016
BOLT
SN: (110186)-UP
1шт.
