Запчасти Komatsu WA430-5 МОДУЛИРУЮЩИЙ КЛАПАН СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$9

714-17-20003

TRANSMISSION ASS'Y

SN: (110604)-UP

1шт.

|$10

714-17-20002

TRANSMISSION ASS'Y

SN: 60001-(110603)

1шт.

|$11

0

TRANSMISSION ASS'Y

SN: (60001-(110185))

1шт.

|$12

0

TRANSMISSION ASS'Y

SN: (60001-(110179))

1шт.

|$13

714-17-20303

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (110604)-UP

1шт.

|$14

714-17-20302

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$15

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$16

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$18

714-17-20013

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (110604)-UP

1шт.

|$19

714-17-20012

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 60001-(110603)

1шт.

|$20

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110185))

1шт.

|$21

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110179))

1шт.

|$22

714-17-20313

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (110604)-UP

1шт.

|$23

714-17-20312

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$24

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$25

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$19

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.

-1шт.

|$31

714-17-25002

VALVE ASS'Y

SN: 60584-UP

1шт.

|$32

0

VALVE ASS'Y

SN: 60001-60583

1шт.

|$33

0

VALVE ASS'Y

SN: (60001-60079)

1шт.

|$34

714-17-25012

VALVE ASS'Y,(WITH LOCKUP)

SN: 60584-UP

1шт.

|$35

0

VALVE ASS'Y,(WITH LOCKUP)

SN: 60001-60583

1шт.

|$36

0

VALVE ASS'Y,(WITH LOCKUP)

SN: (60001-60079)

1шт.

|$37

714-12-25003

VALVE ASS'Y,(COLD TERRAIN SPEC.)

SN: 60001-UP

1шт.

|$38

0

VALVE ASS'Y,(COLD TERRAIN SPEC.)

SN: (60001-60079)

1шт.

|$39

714-12-25013

VALVE ASS'Y,(WITH LOCKUP) (COLD)

SN: 60001-UP

1шт.

|$40

0

VALVE ASS'Y,(WITH LOCKUP) (COLD)

SN: (60001-60079)

1шт.

|$41

714-17-26001

VALVE ASS'Y

SN: 60007-UP

1шт.

|$42

0

VALVE ASS'Y

SN: 60001-60006

1шт.

|$43

714-07-26000

VALVE ASS'Y,(COLD TERRAIN SPEC.)

SN: 60001-UP

1шт.

1

17A-15-25131

BODY

SN: 60001-UP

1шт.

2

07042-20108

PLUG

SN: 60001-UP

2шт.

3

14X-15-15850

PLUG

SN: 60001-UP

1шт.

4

07002-03034

O-RING (K2)

SN: 60001-UP

1шт.

5

714-07-25230

VALVE

SN: 60007-UP

1шт.

5

0

VALVE

SN: 60001-60006

1шт.

6

426-15-15490

VALVE

SN: 60001-UP

1шт.

7

198-15-15770

SPRING, (L= 30.0)

SN: 60001-UP

1шт.

8

426-15-15480

VALVE

SN: 60001-UP

1шт.

9

198-15-15570

SHIM, 0.50MM

SN: 60001-UP

5шт.

10

426-15-16251

SPRING, (L=122.0)

SN: 60001-UP

1шт.

11

426-15-16261

SPRING, (L=108.0)

SN: 60001-UP

1шт.

12

426-15-15810

PLUG

SN: 60001-UP

1шт.

13

07002-03034

O-RING (K2)

SN: 60001-UP

1шт.

14

12H-15-14130

SPOOL

SN: 60001-UP

1шт.

15

104-15-25490

VALVE

SN: 60001-UP

1шт.

16

125-15-15290

SPRING

SN: 60001-UP

1шт.

17

104-15-25480

VALVE

SN: 60001-UP

1шт.

18

14X-15-16210

SPRING

SN: 60001-UP

1шт.

19

12H-15-14140

GUIDE

SN: 60001-UP

1шт.

20

14X-15-15850

PLUG

SN: 60001-UP

2шт.

21

07002-03034

O-RING (K2)

SN: 60001-UP

2шт.

22

175-15-56470

SHIM, 0.50MM,(COLD TERRAIN SPEC. LESS)

SN: 60001-UP

2шт.
