Запчасти Komatsu WA430-5 КЛАПАН КОНТРОЛЯ ПОТОКА ТРАНСМИССИИ СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$9

714-17-20003

TRANSMISSION ASS'Y

SN: (110604)-UP

1шт.

|$10

714-17-20002

TRANSMISSION ASS'Y

SN: 60001-(110603)

1шт.

|$11

0

TRANSMISSION ASS'Y

SN: (60001-(110185))

1шт.

|$12

0

TRANSMISSION ASS'Y

SN: (60001-(110179))

1шт.

|$13

714-17-20303

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (110604)-UP

1шт.

|$14

714-17-20302

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$15

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$16

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$18

714-17-20013

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (110604)-UP

1шт.

|$19

714-17-20012

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 60001-(110603)

1шт.

|$20

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110185))

1шт.

|$21

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110179))

1шт.

|$22

714-17-20313

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (110604)-UP

1шт.

|$23

714-17-20312

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$24

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$25

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$19

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.

-1шт.

|$33

714-17-25401

VALVE ASS'Y

SN: 60021-UP

1шт.

|$34

714-17-25400

VALVE ASS'Y

SN: 60001-60020

1шт.

|$35

714-07-25461

BODY

SN: 60021-UP

1шт.

|$36

714-07-25460

BODY

SN: 60001-60020

1шт.

1

714-07-25151

BODY

SN: 60021-UP

1шт.

1

714-07-25150

BODY

SN: 60001-60020

1шт.

2

07042-80108

PLUG

SN: 60021-UP

2шт.

2

07043-70108

PLUG

SN: 60001-60020

2шт.

3

714-07-15410

VALVE

SN: 60001-UP

1шт.

4

714-07-15420

SPRING

SN: 60001-UP

1шт.

5

714-12-15430

CHOKE

SN: 60001-UP

1шт.

6

714-07-15840

COVER

SN: 60001-UP

2шт.

7

01010-80820

BOLT

SN: 60001-UP

4шт.

8

01643-30823

WASHER

SN: 60001-UP

4шт.

9

07000-73030

O-RING (K2)

SN: 60001-UP

2шт.
