Запчасти Komatsu WA430-5 ТРАНСМИССИЯ (ВЫХОДНОЙ ВАЛ) СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$9

714-17-20003

TRANSMISSION ASS'Y

SN: (110604)-UP

1шт.

|$10

714-17-20002

TRANSMISSION ASS'Y

SN: 60001-(110603)

1шт.

|$11

0

TRANSMISSION ASS'Y

SN: (60001-(110185))

1шт.

|$12

0

TRANSMISSION ASS'Y

SN: (60001-(110179))

1шт.

|$13

714-17-20303

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (110604)-UP

1шт.

|$14

714-17-20302

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$15

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$16

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$18

714-17-20013

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (110604)-UP

1шт.

|$19

714-17-20012

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 60001-(110603)

1шт.

|$20

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110185))

1шт.

|$21

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110179))

1шт.

|$22

714-17-20313

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (110604)-UP

1шт.

|$23

714-17-20312

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$24

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$25

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$19

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.

-1шт.

1

714-12-24521

SHAFT,OUTPUT

SN: (110629)-UP

1шт.

1

714-12-24520

SHAFT,OUTPUT

SN: 60001-(110628)

1шт.

2

714-12-24620

GEAR, 62 TEETH,OUTPUT

SN: 60001-UP

1шт.

3

06002-32215

BEARING

SN: 60001-UP

1шт.

4

06002-32017

BEARING

SN: 60001-UP

1шт.

5

714-12-23830

SPACER

SN: 60001-UP

1шт.

6

714-07-28611

HUB,SPLINE

SN: 60001-UP

1шт.

7

714-12-27141

CAGE

SN: 60001-UP

1шт.

8

714-07-39120

OIL SEAL

SN: (110629)-UP

1шт.

8

07012-50095

SEAL

SN: 60001-(110628)

1шт.

9

714-07-39120

OIL SEAL

SN: (110629)-UP

1шт.

9

07012-50095

SEAL

SN: 60001-(110628)

1шт.

10

425-15-28710

SEAL,DUST (K1)

SN: 60001-UP

1шт.

11

425-15-28710

SEAL,DUST (K1)

SN: 60001-UP

1шт.

12

07000-15140

O-RING (K1)

SN: 60001-UP

1шт.

13

01010-81235

BOLT

SN: 60001-UP

6шт.

14

714-12-27111

HOUSING

SN: 60001-UP

1шт.

15

714-12-27121

HOUSING

SN: 60001-UP

1шт.

16

07000-15275

O-RING (K1)

SN: 60001-UP

1шт.

17

01016-51250

BOLT

SN: 60001-UP

4шт.

18

07043-A0312

PLUG

SN: 60001-UP

2шт.

19

714-07-27161

SPRING

SN: 60001-UP

10шт.

20

714-07-27151

SPRING

SN: 60001-UP

10шт.

21

714-12-27131

PISTON

SN: 60001-UP

1шт.

22

07000-A6210

O-RING (K1)

SN: 60001-UP

1шт.

23

07000-A6260

O-RING (K1)

SN: 60001-UP

1шт.

24

07001-06265

RING (K1)

SN: 60001-UP

1шт.

25

04020-01842

PIN

SN: 60001-UP

2шт.

26

714-07-12670

DISC

SN: 60001-UP

9шт.

27

714-12-19730

PLATE,SEPARATE

SN: 60001-UP

10шт.

28

714-07-12691

SPRING,WAVE

SN: (110039)-UP

9шт.

28

0

SPRING,WAVE

SN: 60001-(110038)

9шт.

29

714-12-17250

PLATE,END

SN: 60001-UP

1шт.

30

714-07-12720

RING,SNAP

SN: 60001-UP

2шт.

31

714-12-00040

SHIM ASS'Y (K1)

SN: 60001-UP

1шт.

31

0

SHIM, 0.05MM

SN: 60001-UP

6шт.

31

0

SHIM, 0.5MM

SN: 60001-UP

4шт.

31

0

SHIM, 0.2MM

SN: 60001-UP

4шт.

32

714-17-24111

COUPLING

SN: 60001-UP

1шт.

32

0

COUPLING

SN: 60001-UP

1шт.

32

0

COVER

SN: 60001-UP

1шт.

33

772-14-13130

HOLDER

SN: 60001-UP

1шт.

34

07000-15060

O-RING (K1)

SN: 60001-UP

1шт.

35

01011-62020

BOLT

SN: 60001-UP

1шт.

36

01643-32060

WASHER

SN: 60001-UP

1шт.

37

714-12-24120

COUPLING ASS'Y

SN: 60001-UP

1шт.

37

0

COUPLING ASS'Y

SN: 60001-UP

1шт.

37

0

COUPLING,REAR

SN: 60001-UP

1шт.

37

0

COVER

SN: 60001-UP

1шт.

37

0

DEFLECTOR

SN: 60001-UP

1шт.
