Запчасти Komatsu WA430-5 ТРАНСМИССИЯ (1 И 4 МУФТА) СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$9

714-17-20003

TRANSMISSION ASS'Y

SN: (110604)-UP

1шт.

|$10

714-17-20002

TRANSMISSION ASS'Y

SN: 60001-(110603)

1шт.

|$11

0

TRANSMISSION ASS'Y

SN: (60001-(110185))

1шт.

|$12

0

TRANSMISSION ASS'Y

SN: (60001-(110179))

1шт.

|$13

714-17-20303

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (110604)-UP

1шт.

|$14

714-17-20302

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$15

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$16

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$18

714-17-20013

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (110604)-UP

1шт.

|$19

714-17-20012

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 60001-(110603)

1шт.

|$20

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110185))

1шт.

|$21

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110179))

1шт.

|$22

714-17-20313

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (110604)-UP

1шт.

|$23

714-17-20312

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$24

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$25

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$19

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.

-1шт.

|$31

714-12-22020

CLUTCH ASS'Y,1ST AND 4TH

SN: 60001-UP

1шт.

1

714-12-22122

SHAFT AND CYLINDER A,1ST AND 4TH

SN: (110637)-UP

1шт.

1

714-12-22121

SHAFT AND CYLINDER A,1ST AND 4TH

SN: 60001-(110636)

1шт.

1

0

SHAFT,UPPER

SN: (110637)-UP

1шт.

1

0

SHAFT,UPPER

SN: 60001-(110636)

1шт.

1

0

HOUSING

SN: (110637)-UP

1шт.

1

0

HOUSING

SN: 60001-(110636)

1шт.

1

0

ORIFICE

SN: 60001-UP

1шт.

1

0

BALL

SN: 60001-UP

2шт.

2

714-07-22661

PISTON,RANGE

SN: 60001-UP

2шт.

3

714-12-19711

DISC

SN: 60001-UP

12шт.

4

714-16-19730

PLATE,SEPARATE

SN: 60001-UP

14шт.

5

56D-15-12710

SPRING,WAVE

SN: (110039)-UP

12шт.

5

0

SPRING,WAVE

SN: 60001-(110038)

12шт.

6

714-12-12610

PLATE,END

SN: 60001-UP

2шт.

7

419-15-12140

RING,SNAP

SN: 60001-UP

2шт.

8

714-16-19220

RING (K1)

SN: 60001-UP

2шт.

9

714-07-19320

RING,SEAL (K1)

SN: 60001-UP

2шт.

10

714-08-19570

WASHER,THRUST

SN: 60001-UP

3шт.

11

714-08-19560

WASHER

SN: 60001-UP

1шт.

12

714-23-19410

BEARING,NEEDLE

SN: 60001-UP

2шт.

13

714-23-19430

BEARING,NEEDLE

SN: 60001-UP

1шт.

14

714-11-12720

SPACER

SN: 60001-UP

1шт.

15

714-07-22550

SNAP RING

SN: 60001-UP

1шт.

16

714-12-22441

GEAR, 64 TEETH,4TH

SN: 60001-UP

1шт.

17

714-12-22431

GEAR, 26 TEETH,1ST

SN: 60001-UP

1шт.

18

714-12-22511

GEAR, 37 TEETH,2ND

SN: 60001-UP

1шт.

19

714-12-19380

BEARING

SN: 60001-UP

1шт.

20

714-12-39340

BEARING

SN: UP

1шт.

20

714-12-29340

BEARING

SN: 60001-UP

1шт.

21

419-15-12122

RING,SEAL (K1)

SN: 60001-UP

3шт.
