Запчасти Komatsu WA430-5 ТРАНСМИССИЯ (МУФТА ВПЕРЕД/РЕВЕРС) (С БЛОКИР.UP) СИЛОВАЯ ПЕРЕДАЧА
№
Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$5
714-17-20013
TRANSMISSION ASS'Y
SN: (110604)-UP
1шт.
|$6
714-17-20012
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: 60001-(110603)
1шт.
|$7
0
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: (60001-(110185))
1шт.
|$8
0
TRANSMISSION ASS'Y,(WITH LOCKUP)
SN: (60001-(110179))
1шт.
|$9
714-17-20313
TRANSMISSION ASS'Y
SN: (110604)-UP
1шт.
|$10
714-17-20312
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: 60001-(110603)
1шт.
|$11
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (60001-(110185))
1шт.
|$12
0
TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)
SN: (60001-(110179))
1шт.
|$$10
THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.
-1шт.
|$17
714-12-22050
CLUTCH ASS'Y,FORWARD AND REVERSE
SN: 60001-UP
1шт.
1
714-12-22151
SHAFT AND CYLINDER A
SN: 60001-UP
1шт.
1
0
SHAFT,INPUT
SN: 60001-UP
1шт.
1
0
PLUG
SN: (110592)-UP
2шт.
1
0
SCREW
SN: 60001-(110591)
2шт.
1
0
ORIFICE
SN: 60001-UP
1шт.
1
0
HOUSING
SN: 60001-UP
1шт.
3
714-07-22652
PISTON,FOWARD AND REVERSE
SN: 60001-UP
2шт.
7
714-07-22720
PLATE
SN: 60001-UP
2шт.
14
714-11-12720
SPACER
SN: 60001-UP
1шт.
15
714-07-22711
SPACER
SN: 60001-UP
1шт.
17
714-12-22421
GEAR, 40 TEETH,FORWARD
SN: 60001-UP
1шт.
18
714-12-22411
GEAR, 31 TEETH,REVERSE
SN: 60001-UP
1шт.
Выбрано товаров: 37
