Запчасти Komatsu WA430-5 ТРАНСМИССИЯ (КОРПУС ТРАНСМИССИИ) СИЛОВАЯ ПЕРЕДАЧА

|$$1

SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.

-1шт.

|$9

714-17-20003

TRANSMISSION ASS'Y

SN: (110604)-UP

1шт.

|$10

714-17-20002

TRANSMISSION ASS'Y

SN: 60001-(110603)

1шт.

|$11

0

TRANSMISSION ASS'Y

SN: (60001-(110185))

1шт.

|$12

0

TRANSMISSION ASS'Y

SN: (60001-(110179))

1шт.

|$13

714-17-20303

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (110604)-UP

1шт.

|$14

714-17-20302

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$15

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$16

0

TRANSMISSION ASS'Y,(WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$10

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A0.

-1шт.

|$18

714-17-20013

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (110604)-UP

1шт.

|$19

714-17-20012

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: 60001-(110603)

1шт.

|$20

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110185))

1шт.

|$21

0

TRANSMISSION ASS'Y,(COLD TERRAIN (A) SPEC.)

SN: (60001-(110179))

1шт.

|$22

714-17-20313

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (110604)-UP

1шт.

|$23

714-17-20312

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: 60001-(110603)

1шт.

|$24

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110185))

1шт.

|$25

0

TRANSMISSION ASS'Y,(COLD SPEC.) (WITH LOCKUP)

SN: (60001-(110179))

1шт.

|$$19

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-63A1.

-1шт.

1

714-12-28112

CASE,FRONT

SN: 60584-UP

1шт.

1

714-12-28111

CASE,FRONT

SN: 60001-60583

1шт.

|$47

714-12-21122

CASE,REAR

SN: 60001-UP

1шт.

2

714-12-28122

CASE,REAR

SN: 60001-UP

1шт.

3

07043-70617

PLUG

SN: 60001-UP

4шт.

4

07043-70415

PLUG

SN: 60001-UP

1шт.

5

07043-70312

PLUG

SN: 60001-UP

1шт.

6

07043-70211

PLUG

SN: 60001-UP

1шт.

7

04020-01228

PIN,DOWEL

SN: 60001-UP

2шт.

8

01010-81240

BOLT

SN: 60001-UP

20шт.

9

01010-81270

BOLT

SN: 60001-UP

6шт.

10

01643-51232

WASHER

SN: 60001-UP

6шт.

11

07000-15285

O-RING (K1)

SN: 60001-UP

1шт.

12

01011-81205

BOLT

SN: 60001-UP

7шт.

13

01011-81210

BOLT

SN: 60001-UP

2шт.

14

01643-31232

WASHER

SN: 60001-UP

2шт.

15

714-12-28140

CAGE

SN: (110161)-UP

1шт.

15

0

CAGE

SN: 60001-(110160)

1шт.

16

714-07-00111

SHIM ASS'Y (K1)

SN: (110384)-UP

1шт.

16

714-07-00110

SHIM ASS'Y (K1)

SN: 60001-(110383)

1шт.

16

0

SHIM, 0.05MM

SN: 60001-UP

6шт.

16

0

SHIM, 0.5MM

SN: (110384)-UP

6шт.

16

0

SHIM, 0.5MM

SN: 60001-(110383)

4шт.

16

0

SHIM, 0.2MM

SN: 60001-UP

4шт.

17

07000-72135

O-RING (K1)

SN: (110161)-UP

1шт.

17

0

O-RING (K1)

SN: 60001-(110160)

1шт.

18

01010-81235

BOLT

SN: 60001-UP

6шт.

19

714-12-24910

COVER,GEAR

SN: 60001-UP

1шт.

20

01011-81200

BOLT

SN: 60001-UP

3шт.

21

01643-31232

WASHER

SN: 60001-UP

3шт.

22

419-15-18131

LIQUID GASKET (K1)

SN: 60001-UP

1шт.
