Запчасти Komatsu WA420-DZ-3 ТРАНСМИССИЯ(4 МУФТА) [ТРАНСМИССИЯ]

|$1

714-17-X0011

TRANSMISSION ASS'Y

Field_2: 10026-

1шт.

|$1

-1шт.

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2201 TO 2271

-1шт.

|$1

-1шт.

|$5

714-07-13500

CLUTCH ASS'Y,3RD AND 4TH

Field_2: 10001-

1шт.

|$1

-1шт.

|$7

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.2225 TO 2226

-1шт.

|$1

-1шт.

1

0

SHAFT ASS'Y

Field_2: 10001-

1шт.

2

714-07-12661

PISTON,4TH

Field_2: 10001-

1шт.

3

714-07-12740

RING,SEAL

Field_2: 10001-

1шт.

4

714-07-19320

RING,SEAL

Field_2: 10001-

1шт.

5

714-07-12670

DISC

Field_2: 10001-

6шт.

6

714-07-12680

PLATE,SEPARATE

Field_2: 10001-

7шт.

7

714-07-12781

SPRING,WAVE

6шт.

|$16

\9\714-07-12780

SPRING,WAVE

6шт.

8

714-07-12711

PLATE,END

Field_2: 10001-

1шт.

9

714-07-12720

RING,SNAP

Field_2: 10001-

1шт.

10

0

GEAR,53 TEETH,4TH

Field_2: 10001-

1шт.

11

56B-15-19420

BEARING,NEEDLE

Field_2: 10026-

2шт.

|$21

714-07-12281

BEARING,NEEDLE

Field_2: 10001-10025

2шт.

12

714-07-12220

WASHER,THRUST

Field_2: 10001-

2шт.

13

714-07-12250

SPACER

Field_2: 10001-

1шт.

14

06040-06215

BEARING

Field_2: 10001-

1шт.

15

714-07-12290

RING,SNAP

Field_2: 10001-

3шт.
