Запчасти Komatsu WA420-3MC FIG. B-BA7 СТАРТЕР - CURRENT ВЕРСИЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$0

1219 521 H92

MOTOR, STARTING

SN: A31120-UP-UP

1шт.

1

1223 255 H1

FRAME

SN: A31120-UP-UP

1шт.

2

88 797

BUSHING

SN: A31120-UP-UP

1шт.

3

1223 256 H1

ARMATURE

SN: A31120-UP-UP

1шт.

4

1228 605 H1

FIELD COIL

SN: A31120-UP-UP

4шт.

5

1223 265 H1

LEAD

SN: A31120-UP-UP

1шт.

6

1228 447 H91

LEVER, HOUSING

SN: A31120-UP-UP

1шт.

7

1307 315 H1

BUSHING, LEVER HOUSING

SN: A31120-UP-UP

1шт.

8

1228 604 H1

DRIVE ASSEMBLY

SN: A31120-UP-UP

1шт.

9

1223 260 H91

DRIVE, HOUSING

SN: A31120-UP-UP

1шт.

10

1211 288 H1

BUSHING, DRIVE HOUSING

SN: A31120-UP-UP

1шт.

11

1284 359 H1

SWITCH

SN: A31120-UP-UP

1шт.

12

1303 561 H1

BRUSH

SN: A31120-UP-UP

4шт.

13

1283 451 H1

SPRING BRUSH

SN: A31120-UP-UP

4шт.

14

1284 360 H91

BRUSH PLATE ASSEMBLY

SN: A31120-UP-UP

1шт.

15

1228 450 H1

PLUNGER

SN: A31120-UP-UP

1шт.

16

1210 071 H1

BOOT

SN: A31120-UP-UP

1шт.

17

1210 073 H1

PLUNGER, SPRING

SN: A31120-UP-UP

1шт.

18

1307 316 H1

SHIFT, LEVER

SN: A31120-UP-UP

1шт.

19

1211 356 H1

WASHER

SN: A31120-UP-UP

1шт.

20

1211 286 H1

WASHER, BRAKE

SN: A31120-UP-UP

1шт.

21

1232 885 H1

WASHER, THRUST

SN: A31120-UP-UP

1шт.

22

120 239

WASHER, LOCK

SN: A31120-UP-UP

-2шт.

23

1211 267 H1

NUT, FLD COIL CONNECTION TO SWITCH ATCH

SN: A31120-UP-UP

1шт.

24

19 839 R1

NUT, PLUNGER ROD GUIDE ADJUSTING

SN: A31120-UP-UP

1шт.

25

1305 531 H1

NUT, ASM SHUNT LEAD TO SWITCH ATCH

SN: A31120-UP-UP

1шт.

26

1249 322 H1

NUT, TERM-CE FRAME

SN: A31120-UP-UP

2шт.

27

1211 267 H1

NUT AND WASHER ASSEMBLY-CE FRAME

SN: A31120-UP-UP

1шт.

28

1211 292 H1

BOLT, BRUSH LEAD AND FLD COIL LEAD

SN: A31120-UP-UP

4шт.

29

1223 263 H1

BOLT AND WASHER ASSEMBLY-CE FRAME ATCH

SN: A31120-UP-UP

6шт.

30

1283 448 H1

BOLT, CONNECTOR TO FIELD ATCH

SN: A31120-UP-UP

3шт.

31

1251 333 H1

BOLT, DRIVE HSG ATCH

SN: A31120-UP-UP

6шт.

32

1245 107 H1

BOLT, LEVER HSG ATCH

SN: A31120-UP-UP

5шт.

33

1245 108 H1

BOLT, POLE SHOE

SN: A31120-UP-UP

8шт.

34

1439 193 H1

STUD

SN: A31120-UP-UP

1шт.

35

1307 320 H1

WASHER

SN: A31120-UP-UP

1шт.

36

1210 070 H1

WASHER, PLUNGER ASSEMBLY

SN: A31120-UP-UP

1шт.

37

1307 320 H1

WASHER, TERM-CE FRAME

SN: A31120-UP-UP

1шт.

38

1250 268 H1

CONNECTOR, FLD TERM TO SWITCH

SN: A31120-UP-UP

1шт.

39

1307 318 H1

CUP, OIL RESERVOIR, CE

SN: A31120-UP-UP

1шт.

40

1211 277 H1

CUP, OIL RESERVOIR-DE

SN: A31120-UP-UP

1шт.

41

1307 318 H1

CUP, OIL RESERVOIR-LEVEL HSG

SN: A31120-UP-UP

1шт.

42

1211 151 H1

GASKET, INSPECTION PLUG-LEVER HSG

SN: A31120-UP-UP

1шт.

43

1228 453 H1

INSULATOR, FLD COIL-CE

SN: A31120-UP-UP

1шт.

44

1210 061 H1

INSULATOR, FLD TERM - INSIDE FRAME

SN: A31120-UP-UP

1шт.

45

1210 062 H1

INSULATOR, FLD TERM - OUTSIDE FRAME

SN: A31120-UP-UP

1шт.

46

1223 269 H91

INSULATION, PKG-CE TERM

SN: A31120-UP-UP

1шт.

47

1277 066 H1

LEAD, CE TERM TO SOLENOID SWITCH

SN: A31120-UP-UP

1шт.

48

1307 319 H1

O-RING, BETWEEN SWITCH AND LEVER HSG

SN: A31120-UP-UP

1шт.

49

347 360 R1

O-RING, BETWEEN DR HSG AND LEVER HSG

SN: A31120-UP-UP

1шт.

50

22 411 R1

O-RING, BETWEEN LEVER HSG AND FRAME

SN: A31120-UP-UP

1шт.

51

1307 321 H1

O-RING, ON MOTOR FRAME CE END

SN: A31120-UP-UP

1шт.

52

352 219 R1

O-RING, SHIFT LEVER SHAFT - 3/8 IN. OD

SN: A31120-UP-UP

1шт.

53

355 967 R1

O-RING, SHIFT LEVER SHAFT - 1/2 IN. OD

SN: A31120-UP-UP

1шт.

54

1228 454 H1

PIN, SPRING - IN FRAME

SN: A31120-UP-UP

2шт.

55

1210 066 H1

PLUG, INSPECTION - LEVER HSG

SN: A31120-UP-UP

1шт.

56

1211 263 H1

POLE, SHOE

SN: A31120-UP-UP

4шт.

57

1210 072 H1

RETAINER, PLUNGER SPRING - 1-13/64 HOLE

SN: A31120-UP-UP

1шт.

58

1210 074 H1

RETAINER, PLUNGER SPRING - 13/32 HOLE

SN: A31120-UP-UP

1шт.

59

1211 285 H1

SEAL, OIL - LEVER HSG

SN: A31120-UP-UP

1шт.

60

1211 152 H1

SEAL, SHIFT LEVER

SN: A31120-UP-UP

1шт.

61

1305 530 H1

TERMINAL, SHIELD

SN: A31120-UP-UP

1шт.

62

213 262 R1

SNAP RING, PLUNGER ASSEMBLY

SN: A31120-UP-UP

1шт.

63

213 262 R1

SNAP RING, SHIFT LEVER SHAFT

SN: A31120-UP-UP

1шт.

64

1307 322 H1

WICK, OIL RESERVOIR-CE

SN: A31120-UP-UP

1шт.

65

1302 333 H1

WICK, OIL RESERVOIR-DE

SN: A31120-UP-UP

1шт.

66

1307 323 H1

WICK, OIL RESERVOIR-LEVER HSG

SN: A31120-UP-UP

1шт.

67

103 088

NUT - M10-32

SN: A31120-UP-UP

1шт.

68

1308 919 H1

SHIELD WIRING

SN: A31120-UP-UP

1шт.

|$69

-1шт.

|$70

SERVICE REPAIR KITS

-1шт.

|$71

-1шт.

|$72

1223 268 H91

24 VOLT BRUSH REPAIR KIT

SN: A31120-UP-UP

1шт.

|$73

1223 266 H91

BUSHING REPAIR KIT

SN: A31120-UP-UP

1шт.

|$74

1223 267 H91

SHIFT LEVER REPAIR KIT

SN: A31120-UP-UP

1шт.

|$75

-1шт.

|$76

F1 - INCLUDED IN 24 VOLT BRUSH REPAIR KIT.

-1шт.

|$78

-1шт.

|$79

F2 - INCLUDED IN BUSHING REPAIR KIT.

-1шт.

|$81

-1шт.

|$82

F3 - INCLUDED IN SHIFT LEVER REPAIR KIT.

-1шт.

|$83

-1шт.
